DJI Goggles compatibility guide: Supported drones & key specs

Q: What are the differences between DJI Goggles 2, DJI Goggles Integra, and DJI Goggles 3? What improvements have been made to DJI Goggles 3?

The differences include: DJI Goggles 3 and DJI Goggles 2 are similar in size and screen display performance. However, Goggles 3 exhibits significant enhancements in video transmission. When paired with Avata 2, they can achieve a minimum transmission latency of 24 milliseconds. Compared to DJI Goggles 2 and DJI Goggles Integra, DJI Goggles 3 innovates with an integrated forehead pad design, offering superior comfort. The new Real View PiP feature enhances safety during takeoff and landing.

Q: What are the main differences of DJI Goggles N3 compared with other DJI goggles?

The DJI Goggles N3 features a more spacious internal design than the DJI Goggles 3, accommodating personal glasses without requiring diopter adjustments or additional lenses. It has a single 1080p ultra-wide screen with a 54° field of view, reducing the likelihood of dizziness and enhancing immersion. In comparison to the DJI Goggles Integra and DJI Goggles 2, the N3 incorporates DJI's latest O4 FHD video transmission technology, a ready-to-use design, and an extended battery life of up to 2.7 hours*. It also includes features such as AR Cursor** and One-Tap Defogging, and is compatible with more of DJI's latest drones and remote controllers for an improved user experience. *The 2.7-hour maximum operating time was measured at 25°C, with screen brightness at 6, connected to the DJI Avata 2 with video transmission set to 1080p/100fps, Head Tracking off, and the battery fully charged without powering external devices. **This feature requires the DJI RC Motion 3. For more details about compatibility, visit our DJI Goggles drone compatibility guide.

Q: Which DJI goggles work with which drones?

DJI goggles are not universally compatible. For more details about compatibility, visit our DJI Goggles drone compatibility guide.

Q: Can I use DJI Goggles with enterprise drones?

Generally, DJI Enterprise drones do not support goggles. Enterprise platforms prioritise situational awareness, safety observers, and mission workflows rather than immersive FPV-style viewing. For more details about compatibility, visit our DJI Goggles drone compatibility guide.

Q: Can I connect DJI Goggles to third-party drones?

No. DJI goggles are designed to work only within DJI’s ecosystem and are not compatible with third-party drones or analogue FPV systems without additional hardware and workarounds. For more details about compatibility, visit our DJI Goggles drone compatibility guide.

Q: Is firmware important for DJI Goggles compatibility?

Yes — firmware is critical. Both the goggles and the drone must be running compatible firmware versions. Incompatibility issues are often resolved (or caused) by firmware updates. For more details about compatibility, visit our DJI Goggles drone compatibility guide.

Find out which DJI Goggles work with which DJI drones, motion controllers and remotes, plus key features of DJI's goggle range.

DJI Goggles provide an immersive FPV experience for DJI drones.

But which goggles are compatible with which DJI drone? And what are the key features of the DJI Goggle range?

Find out in this guide.

DJI Goggles compatibility list

Model	DJI Neo 2	DJI Mini 5 Pro	DJI Mavic 4 Pro	DJI Flip	DJI 04 Air Unit	DJI Air 3S	DJI Neo	DJI Avata 2	DJI Avata	DJI Mini 4 Pro	DJI Mini 3 Pro	DJI Air 3	DJI Mavic 3 Series	DJI FPV
DJI Goggles N3	✓	x	x	x	✓	x	✓	✓	x	x	x	x	x	x
DJI Goggles 3	✓	x	x	x	✓	x	✓	✓	x	✓	x	✓	x	x
DJI Goggles Integra	x	x	x	x	✓	x	x	✓	✓	✓	✓	✓	✓	✓
DJI FPV Goggles V2	x	x	x	x	x	x	x	x	✓	x	x	x	x	✓
DJI Goggles 2	x	x	x	x	✓	x	x	✓	✓	✓	✓	✓	✓	✓
DJI RC Motion 3	✓	x	x	x	x	x	✓	✓	x	✓	x	✓	x	x
DJI RC Motion 2	x	x	x	x	x	x	x	✓	✓	✓	✓	✓	✓	x
DJI RC Motion	x	x	x	x	x	x	x	x	✓	x	x	x	x	✓
DJI FPV Remote Controller 3	✓	x	x	x	✓	x	✓	✓	x	x	x	x	x	x
DJI FPV Remote Controller 2	x	x	x	x	✓	x	x	✓	✓	x	x	x	x	✓
DJI FPV Remote Controller 1	x	x	x	x	x	x	x	x	x	x	x	x	x	x

DJI Goggles: At a glance

DJI Goggles 3: DJI’s most advanced model with O4 transmission, immersive features, comfort upgrades, and long runtime — ideal for FPV pros and enthusiasts.
DJI Goggles N3: Blends affordability with modern tech like O4 transmission and wide FOV, but uses a single LCD screen rather than dual OLEDs.
DJI Goggles 2 and DJI Integra: Share many core FPV features with dual screens and robust transmission, but without the highest-end extras of the Goggles 3.
DJI Goggles V2: Reflects DJI’s earlier FPV goggles generation and is largely relevant for older hardware.

	DJI Goggles N3	DJI Goggles 3	DJI Goggles Integra	DJI FPV Goggles V2	DJI Goggles 2
Weight	536g (battery and headband included)	Approx. 470 g (battery included)	Approx. 410 g (battery included)	Approx. 420 g (headband and antennas included)	Approx. 290 g (headband included)
Dimensions (L x W x H)	With antennas folded: 193 x 163 x103 mm With antennas unfolded: 206 x 163 x 132 mm	With antennas folded: 170 x 109 x 112 mm With antennas unfolded: 205 x 109 x 112 mm	With antennas folded: 170 x 104 x 75 mm With antennas unfolded: 205 x 104 x 104 mm	With antennas: 202 x 126 x 110 mm Without antennas: 184 x 122 x 110 mm	With antennas folded: 167.40 x 103.90 x 81.31 mm With antennas unfolded: 196.69 x 103.90 x 104.61 mm
Screen Size (single screen)	3.5 inches	0.49 inch	0.49-inch	2-inch	0.49-inch
Resolution (single screen)	1920 x 1080	1920 x 1080	1920 x 1080	1440 × 810	1920 x 1080
Refresh Rate	Up to 60 Hz	Up to 100 Hz	Up to 100 Hz	144 Hz	Up to 100 Hz
IPD Range	No interpupillary distance adjustment required, ready to use immediately.	56-72 mm	56-72 mm	58 -70 mm	56-72 mm
FOV (single screen)	54°	44°	44°	30° to 54°	51°
Real view display	Not supported	44°	Not supported	Not supported	Not supported
Max transmission distance (CE)	With DJI Avata 2: 10km With DJI Neo: 6km	With DJI Avata 2: 10km	2km to 6km, depending on drone	6km	2km to 6km, depending on drone
Transmission latency	With DJI Avata 2: 1080p/100fps video transmission quality: Minimum 31 ms With DJI Neo: 1080p/60fps video transmission quality: Minimum 58 ms	With DJI Avata 2: 1080p/100fps video transmission quality: Latency down to 24 ms 1080p/60fps video transmission quality: latency down to 40 ms	1080p/100fps: as low as 30 ms 1080p/60fps: as low as 40 ms	810p/120fps: latency is less than 28ms 810p/60fps: latency is less than 40ms	1080p/100fps Video Transmission Quality: The latency is as low as 30 ms. 1080p/60fps Video Transmission Quality: The latency is as low as 40 ms.
Max video bitrate	With DJU Avata 2: 60 Mbps With DJI Neo: 50 Mbps	60 Mbps	50 Mbps	50 Mbps	50 Mbps
Runtime	2.7 hours	Approx 3 hours	Approx 2 hours	Approx 1hr 50mins	2 hours
