DJI Neo 2 Digital Transceiver: installation and linking guide

This guide explains how to install the DJI Neo 2 Digital Transceiver and link your aircraft, remote controller, and goggles in a few simple steps.

Installing the Digital Transceiver

The DJI Neo 2 Digital Transceiver must be installed when using the aircraft with a remote controller or goggles.

1. Insert the USB-C connector on the transceiver into the port at the rear of the aircraft.

2. Align the screw holes and tighten the four screws using the screwdriver provided in the aircraft package.

3. Check that the transceiver is firmly in place. If the antenna is slightly tilted, gently move it into the correct position.

4. Once installed, the aircraft can be charged or connected to a computer through the same USB-C port.

Linking the aircraft and remote controller

Power on the aircraft and the remote controller. Keep both devices within 0.5 metres of each other during linking.

1. Connect the remote controller to your smartphone and open the DJI Fly app.

2. Tap Connection Guide in the bottom-right corner of the home screen.

3. Select the correct aircraft model and follow the on-screen steps.

4. Press and hold the aircraft power button until it beeps.

5. Tap the Linking button in the app.

6. When linking is successful, the live view will appear in DJI Fly.

Linking the aircraft and goggles

1. Power on the aircraft and the goggles. Keep both within 0.5 metres during linking.

2. On the goggles, press the 5D button to open the menu.

3. Select Status to confirm the device model shown at the top of the menu.

4. Tap Switch in the upper-right corner if needed, then select the correct aircraft model.

5. Press and hold the aircraft power button until it beeps once and the battery LEDs begin flashing in sequence.

6. Press and hold the goggles’ power button until they beep continuously and the power button flashes yellow.

7. When linking is complete, the aircraft LEDs turn solid to show battery level, the goggles stop beeping, and video transmission displays normally.

Linking the goggles and RC (Motion Controller)

1. Press and hold the goggles’ power button until they beep continuously and the power button flashes yellow.

2. Press and hold the motion controller’s power button until it beeps continuously and the battery LEDs begin flashing in sequence.

3. When linking is complete, both devices stop beeping and the battery level displays normally.
