DJI Neo 2 - First Use Guide (RC-N3)

A simple guide to setting up the DJI Neo 2 with the DJI RC-N3, covering activation, firmware updates and basic flight controls.

This guide shows you how to set up the DJI Neo 2 with the DJI RC-N3, including activation, firmware updates and the essential controls for your first flight.

Installing DJI Fly

The DJI Fly app is required to operate the aircraft.

Scan the QR code on the package to download and install the latest version.

Preparing the aircraft

  1. Press down to remove the gimbal protector

  2. Press the power button once to activate the battery and check the battery level.

The aircraft includes internal storage. When powered off, the USB-C port can be used for charging.

Press once, then press and hold the power button for two seconds to power on the aircraft.

Preparing the RC

  1. Remove the control sticks from their storage slots and attach them to the controller.

  2. Pull out the mobile device holder to access the remote controller cable.

  3. Check that the connector marked with an RC icon is securely inserted.

  4. Remove the other connector, unwind it to the right, and place it behind the non-slip pads.

  5. Place your smartphone in the holder with the charging port on the right, then secure it.

  6. Connect the remote controller cable.

  7. Press once, then press and hold the power button for two seconds to power on the remote controller.

Activating the devices

  1. Open DJI Fly on the smartphone.

  2. Log in with your DJI account. New users must register before logging in.

  3. Follow the on-screen instructions to activate the aircraft. An internet connection is required.

If you plan to purchase DJI Care Refresh, complete the purchase and binding within 48 hours of activation. You may skip this step if not required.

Updating firmware

If a firmware update is available, a prompt will appear.

Tap the prompt, then tap Update to update all devices.

For safety and best performance, update to the latest firmware immediately.

Do not power off the aircraft or exit DJI Fly during the update.

After updating, the aircraft will power off automatically.

Pre-flight checks

  1. Ensure the flight environment is open, bright, and free from obstacles.

  2. Positioning works best on surfaces with clear, visible patterns.

  3. Check that the Intelligent Flight Battery, digital transceiver, propellers, and propeller guards are securely fitted.

  4. Place the aircraft on level ground with the rear facing you.

  5. Set the flight mode switch on the controller to Normal Mode.

  6. Open DJI Fly, go to System Settings > Safety, set obstacle avoidance to Bypass or Brake, and set the RTH height higher than any nearby obstacles.

  7. Confirm the GNSS icon stays white before take-off and that “Home Point Updated” appears in DJI Fly.

Auto take-off and landing

Tap the Take-off icon on the left side of the screen, then press and hold to enable Auto Take-off.

The aircraft will lift and hover automatically.

To land automatically, tap the Landing icon and press and hold to confirm.

Manual take-off and landing

Push both sticks inward or outward to start the motors.

Gently push the left stick up to take off manually.

To land, pull the left stick down.

Basic flight controls

Left stick:

  • Up / down – ascend / descend

  • Left / right – rotate the aircraft

Right stick:

  • Up / down – fly forward / backward

  • Left / right – fly horizontally left / right

Keep the controller positioned to maintain a strong signal during flight.

Camera controls

  1. Press the Photo/Video button to switch between photo and video modes.

  2. Tap the camera icon in DJI Fly to switch between Auto and Manual mode.

  3. Tap the parameter menu to adjust camera settings.

  4. Press the Shutter/Record button to take photos or start/stop recording.

  5. Use the gimbal dial to control gimbal tilt.

  6. Tap Playback to view or download your footage.

Return to Home (RTH)

Press and hold the RTH button on the remote controller, or tap the RTH icon in DJI Fly and hold to confirm.

The aircraft will fly back to the most recent Home Point and land automatically.

Press the power button once, then press and hold for two seconds to power off both the aircraft and the remote controller.

After the flight

  1. Check and clear any debris from the aircraft body and sensors.

  2. Reattach the gimbal protector.

  3. When storing the aircraft, avoid applying long-term pressure to the digital transceiver antennas to prevent deformation.

  4. Fold the antennas, remove the control sticks, and store them in the controller’s slots.
