Dimensions | 139.7 x 42.2 x 33.5mm (L x W x H) |
Weight | 179g |
Number of microphones | 3 |
Touchscreen | Size: 2.0 inches Resolution: 314 x 556 Brightness: 700 nits |
Supported SD cards | microSD (up to 512 GB) |
Reccommended microSD cards | Recommended models: SanDisk Extreme Pro 32GB V30 A2 UHS-I Speed Grade 3 Kingston Canvas Go!Plus 64GB UHS-I Speed Grade 3 Kingston Canvas Go!Plus 128GB UHS-I Speed Grade 3 Kingston Canvas React Plus 64GB UHS-II Speed Grade 3 Kingston Canvas React Plus 128GB UHS-II Speed Grade 3 Kingston Canvas React Plus 256GB UHS-II Speed Grade 3 Lexar Pro 256GB SDXC UHS-I V30 R160/W120 (1066x) Lexar Pro 512GB SDXC UHS-I V30 R160/W120 (1066x)
|
Gimbal |
Controllable range | Pan: -235° to 58° Tilt: -120° to 70° Roll: -45° to 45°
|
Mechanical range | Pan: -240° to 63° Tilt: -180° to 98° Roll: -220° to 63°
|
Max controllable speed | 180.0°/s |
Angular vibration range | ±0.005° |
Camera |
Sensor | 1-inch CMOS |
Lens | Format Equivalent: 20 mm Aperture: f/2.0 Focus Range: 0.2 m to ∞ |
ISO range | Photo: 50-6400 Video: 50-6400 Low-Light Video: 50-16000 |
Electronic shutter speed | Photo: 1/8000-1 s Video: 1/8000 s to the limit of frames per second |
Max image size | 16:9, 3840 x 2160
1:1, 3072 x 3072 |
Zoom | Digital Zoom Photo: 3840 x 2160, 2x Video: 1080p, 4 x; 2.7K, 3 x; 4K, 2x
UVC & Livestream: 1080p, 4x Slow Motion/Timelapse: Not available |
Still Photography Modes | Single Shot: Approx. 9.4 MP Countdown: Off/3/5/7 s Panorama: 180°, 3 x 3 |
Normal Video | 4K (16:9): 3840×2160@24/25/30/48/50/60fps 2.7K (16:9): 2688×1512@24/25/30/48/50/60fps 1080p (16:9): 1920×1080@24/25/30/48/50/60fps 3K (1:1): 3072×3072@24/25/30/48/50/60fps 2160p (1:1): 2160×2160@24/25/30/48/50/60fps 1080p (1:1): 1080×1080@24/25/30/48/50/60fps 3K (9:16): 1728×3072@24/25/30/48/50/60fps 2.7K (9:16): 1512×2688@24/25/30/48/50/60fps 1080p (9:16): 1080×1920@24/25/30/48/50/60fps |
Slow motion | 4K (16:9): 3840×2160@120fps 2.7K: 2688×1512@120fps
1080p: 1920×1080@120/240fps |
Hyperlapse | 4K/2.7K/1080p@25/30fps: Auto x 2, x 5, x 10, x 15, x 30 |
Motionlapse | 4K/2.7K/1080p@25/30fps Intervals: 0.5/1/2/3/4/5/6/8/10/15/20/25/30/40/60 s
Duration: 5/10/20/30 mins, 1/2/3/5/∞ hours |
Low-light Video | 4K/2.7K/1080p@25/30fps
Intervals: 0.5/1/2/3/4/5/6/8/10/15/20/25/30/40/60 s
Duration: 5/10/20/30 mins, 1/2/3/5 hours
Supports setting four positions |
Max Video Bitrate | 130 Mbps |
Supported file sytem | exFAT |
Photo format | JPEG/RAW |
Video format | MP4 (H.264/HEVC) |
Built-in Storage Capacity | The camera does not have built-in storage, but storage capacity can be expanded by inserting a microSD card. |
Audio Output | 48 kHz 16-bit; AAC |
Battery |
Type | LiPo |
Capacity | 1300 mAh |
Energy | 10.01 Wh |
Voltage | 7.70 V |
Operating temprature | 0° to 40° C (32° to 104° F) |
Charging temprature | 5° to 45° C (41° to 113° F) |
Operating Time | 166 mins.
Tested at room temperature (25° C/77° F) and 1080p/24fps (16:9), with Wi-Fi off and screen off. This data is for reference only. |
Charging Time | 16 mins to 80%; 32 mins to 100% Tested in a laboratory environment with the DJI 65W PD charger (sold separately). |
Connection |
Wi-Fi operating frequency | 2.400-2.4835 GHz 5.150-5.250 GHz 5.725-5.850 GHz |
Wi-Fi Protocol | 802.11 a/b/g/n/ac |
Wi-Fi transmitter power (EIRP) | 2.4 GHz: < 23 dBm (FCC),< 20 dBm (CE/SRRC/MIC)
5.1 GHz: < 23 dBm (FCC/SRRC), < 20 dBm (CE)
5.8 GHz: < 23 dBm (FCC/SRRC), < 14 dBm (CE) |
Bluetooth Operating Frequency | 2.400-2.4835 GHz |
Bluetooth transmitter power (EIRP) | < 14 dBm |
Bluetooth protocol | BLE 5.2, BR/EDR |
