Which aircraft is compatible with Zenmuse S1? Which gimbal port can be used?

DJI Matrice 400, Matrice 350 RTK and Matrice 300 RTK. The only compatible remote controller for Matrice 350 RTK and Matrice 300 RTK is DJI RC Plus. Before using, please update the drone and the remote controller to the latest firmware. It can be mounted onto any gimbal connector on Matrice 400, Matrice 350 RTK or Matrice 300 RTK.

What is Zenmuse S1 max illumination?

The maximum illuminance of the S1 depends on which DJI drone is used: 40 lux @ 100 m (Matrice 400) 35 lux @ 100 m (Matrice 350 RTK/Matrice 300 RTK)

What is the illumination range of Zenmuse S1?

The Low Beam mode and the Both On mode have an FOV of 15°, corresponding to an illuminated area of approximately 544 m² at a distance of 100 m. The High Beam mode has an FOV of 4°, corresponding to an illuminated area of approximately 38 m² at a distance of 100 m.

What precaution should be taken when using Zenmuse S1?

When using the searchlight in high-humidity environments, fogging may occur. This does not affect its optical performance during use. After use, place the searchlight in a dry, ventilated area for a short period to allow the fog to dissipate naturally. At night, the searchlight may trigger false obstacle avoidance. Depending on the situation, disable obstacle avoidance and operate the aircraft and searchlight in relatively open, unobstructed areas. Do not directly touch the searchlight lens or scratch its surface coating with hard objects, as this will reduce light output efficiency and affect luminous flux and illuminance. When cleaning the lens, use only a soft, dry cloth. Never use alkaline cleaners. Store the searchlight in a safe case in a dry, ventilated environment with an ambient humidity of 40–50%.

DJI Zenmuse S1 (Searchlight)

£0.00

Tax included in UK & Shipping calculated at checkout

50-days return policy
Return your item within 50 days of purchase.
Full refund available for unopened, sealed, and unactivated items.
Opened products may still qualify for a refund - if unused.
For orders over £100, heliguy™ can arrange your return via DPD or in-person drop-off - just contact us.
Next-day delivery - order before 3 pm
Order before 3pm (Monday–Friday) for next-working-day delivery across most of the UK*. Free on orders over £99.
UK Saturday delivery (at additional cost) available on orders placed before 3pm Friday*.
Orders placed after 3pm Friday dispatched on Monday.
No deliveries on Sundays or Bank Holidays.
* Some UK regions - such as Northern Ireland, Channel Islands, Isle of Man, Scottish Highlands & Islands, and Scilly Isles - may require 2-3 working days for delivery.

The DJI Zenmuse S1 is a compact, high-intensity spotlight designed for the DJI Matrice 400, DJI Matrice 350 RTK, and DJI Matrice 300 RTK, delivering powerful illumination with low power consumption. With a maximum centre brightness of up to 40 lux at 100 metres and effective observation up to 500 metres when paired with a camera payload, it's ideal for public safety and inspection missions in low-light environments.

Precision Lighting for Every Mission

A compact, efficient searchlight designed for public safety and inspection scenarios.

Multiple Lighting Modes: Low beam, high beam, both-on, and strobe modes for diverse operational needs.
High-Intensity Illumination: Up to 40 lux at 100 metres, enabling visibility over 500 meters alongside camera payloads.
Sturdy Payload: Designed for tough conditions, the searchlight features an IP54 rating and operates reliably in temperatures ranging from -20°C to 40°C.
Energy-Efficient Performance: Rated at 68W (with M350 and M300) and 120W with DJI M400.
Lightweight and Flexible: Compact design fits any gimbal port, supports gimbal follow, and integrates seamlessly with camera payloads and voice speakers.
Flexible Installation: Compatible with DJI M400, DJI M350 RTK, and DJI M300. The DJI RC Plus is required when using the S1 with either the M350 or M300.
Enhanced Reliability: Equipped with load temperature, over-current, and power protections, along with eye-safe design and stable brightness over long durations.
Convenient Operation: Quick remote controller shortcuts for fast light adjustments.
Synchronised Control: When two Zenmuse S1 are mounted on DJI Matrice 400, both spotlights can be controlled at the same time.
Collaborative Operations: When used with DJI Matrice 400 and Zenmuse H30 Series, Zenmuse S1 supports remote real-time video viewing and spotlight control through DJI FlightHub 2.

A Lighting Mode for Every Scenario

Multiple light modes tailored for both short and long-range applications.

Low Beam Mode: Covers a 15° FOV within 150 metres, suitable for most short-range search and inspection tasks.
High Beam Mode: Delivers strong light penetration with LEP laser white light technology, offering a 4° FOV and optimal coverage for inspections beyond 300 meters.
Both-On Mode: Combines low and high beam outputs to provide maximum illumination, covering near and far fields up to 500 metres.
Strobe Mode: Features a 5Hz strobe flash, ideal for emergency rescue and public safety situations that require increased attention.

Efficient and Reliable High-Intensity Lighting

Maximised illumination with lower power consumption and enhanced user safety.

Max Central Illuminance: Delivers up to 40 lux at 100m (depending on which drone is used), ensuring clear target visibility in low-light conditions.
Power-Efficient Design: Rated power of 68W with DJI M350 or M300, or 120W with DJI Matrice 400. S1 has a high beam power of 24W, allowing for extended flight times.
Convenient Shortcut Operations: Remote control buttons (C1, C2, C3) offer quick access to switching lights, adjusting brightness, and changing lighting modes.
Enhanced Safety Measures: Maintains surface temperatures below 50°C and automatically limits brightness when on the ground to prevent glare and accidental burns.
Robust Payload Protection: Includes safeguards for load temperature, over-current, and power, ensuring stable and reliable performance.

Seamless Gimbal Integration for Enhanced Tracking

Optimised lighting and payload control for precision missions.

Synchronised Gimbal Adjustment: Adjust the searchlight and other payload angles (e.g. H30 series) simultaneously.
Precision Optical Centring: Align the optical centre to support high-magnification zoom for improved detail.
Intelligent Object Tracking: Automatically follows the camera’s field of view to maintain continuous illumination of the target area, ensuring clear visuals in low-light conditions.
Efficient Mission Support: Quickly locate and illuminate targets during SAR and inspection missions, improving overall efficiency.
Synchronised Control: When two Zenmuse S1 are mounted on Matrice 400, both spotlights can be controlled at the same time, including turning the light on/off, brightness adjustment, and gimbal angle control. This feature is ideal for scenarios requiring large-area illumination, such as nighttime search and rescue operations.
Collaborative Ground and Air Operations: When used with Matrice 400 and the Zenmuse H30 Series, Zenmuse S1 supports remote real-time video viewing and spotlight control through DJI FlightHub 2.

Versatile Scenarios for Public Safety Operations

Enhancing night-time rescue, patrol, and inspection missions.

Search and Rescue (SAR): Provides vital illumination in low-light environments, assisting in locating missing persons and stranded individuals.
Disaster Response Lighting: Enhances rescue efforts during natural disasters like earthquakes or floods by offering temporary, focused illumination.
Security Patrol Assistance: Supports night patrols of industrial parks, oil pipelines, and critical infrastructure, improving overall security and incident response times.
Emergency Utility Repairs: Delivers targeted lighting to facilitate quick diagnosis and repair of power facility malfunctions in dark environments.
Night-time Inspections: Aids inspection crews by illuminating transmission lines and identifying damage, foreign objects, or abnormal heat spots, increasing efficiency and accuracy.
