DJI Dock 3: Everything You Need to Know

Learn about the key features, upgrades and uses of DJI Dock 3, the first vehicle-mounted drone-in-a-box solution.

  • We explore the key features of Dock 3, including its improved design and faster takeoffs.

  • As DJI's first-ever portable drone dock, Dock 3 enables seamless on-the-go operations.

  • FlightHub 2 introduces real-time object detection and automated mission planning.

  • Enhanced performance improved weather resistance, and increased safety.

  • Discover how Dock 3 supports emergency response, inspections, and surveying.

DJI Dock 3 is the next-generation drone-in-a-box solution, built for mobile deployment, improved safety, and smarter operations.

Whether used for infrastructure inspections, emergency response, or security monitoring, it delivers faster takeoff, improved weather resistance, and advanced flight capabilities.

This guide provides a detailed breakdown of DJI Dock 3's features, supported aircraft, deployment flexibility, and accessory updates.

Mobile Deployment Capabilities

DJI Dock 3 supports mobile deployment, enabling drones to launch and land from moving vehicles like pickup trucks. This makes it ideal for emergency response, on-demand inspections, and remote surveillance.

Quick Setup:

  • Park the vehicle in a stable position.

  • Configure and launch the drone using FlightHub 2.

Key Upgrades

Improved Dock Design

  • 8° Tilt Cover: Prevents rain buildup and ensures smooth operation in harsh conditions.

  • IP56 Weather Resistance: Handles temperatures from -30°C to 50°C.

  • Advanced Sealing System: Maintains internal temperature at 15°C even at -21°C external temperatures.

  • External RTK Antenna: Enables faster RTK convergence and flexible setup near buildings.

Faster Takeoff & Flight Operations

  • One-click takeoff from FlightHub 2

  • Takes off in 15 seconds

  • Reaches 100m altitude within 100 seconds

  • Enhanced wind resistance: From 8m/s to 12m/s during takeoff and landing

These improvements make Dock 3 highly effective for rapid deployment missions in critical situations.

Compatible Aircraft: Matrice 4D & Matrice 4TD

Pair the DJI Matrice 4D series drones with Dock 3. They share many features with the Matrice 4 Enterprise series, with the added benefit of an IP55 rating and a more robust, fixed-arm design for enhanced durability.

Operators can purchase the Matrice 4D series drones separately and later integrate Dock 3.

Key Features of the M4D Series:

  • IP55-rated durability for reliable performance in harsh conditions.

  • Laser range finder for precise object tracking.

  • 3x and 7x zoom cameras for detailed inspections.

  • Live pinpoint sharing to enhance team collaboration.

  • The M4T features a smaller wide camera, 640×512 thermal imaging, and near-infrared night mode.

Add-ons include:

  • DJI RC Plus 2 Enterprise remote controller

  • Relay functionality: One drone extends video transmission range for another, ideal for mountainous search & rescue operations.

FlightHub 2 Intelligent Features

1. Real-Time Object Detection

  • Automatically identifies and counts vehicles, boats, or other objects.

  • Displays real-time tallies for improved situational awareness.

2. Change Detection

  • Captures before-and-after images from the same location.

  • FlightHub 2 highlights differences and generates reports.

3. Automated Missions with Smart Actions

If certain conditions are met (e.g., high temperature detected), the drone can:

  • Take photos

  • Record video

  • Pause & alert operators

  • Trigger security responses

These features enhance patrol efficiency and autonomous monitoring.

Accessory Updates for DJI Dock 3

Accessory

Function

D-RTK 3

Centimetre-level positioning, extends transmission range

Obstacle Sensing Module

Uses millimetre-wave radar & LiDAR for precise avoidance

DJI AL1 Spotlight

Adjustable illumination for night operations

DJI AS1 Speaker

300m broadcasting range, supports text-to-speech & audio imports

System Safety & Regulatory Compliance

  • Flight Termination System (FTS): Ensures safe landings in case of communication loss.

  • GeoCaging: Restricts flights to designated areas.

  • EU C-Mark Certification: DJI is working towards full regulatory compliance.

  • New PSDK Mount: E-Port Lite supports third-party parachute integration, enhancing safety for BVLOS (Beyond Visual Line of Sight) operations.

Data Security & Privacy Protection

DJI FlightHub 2 provides secure and flexible data management with robust security measures and multiple deployment options to suit various operational needs.

It is ISO 27001 and ISO 27701 certified, ensuring compliance with global information security standards in design, development, and operation.

Cloud and Private Server Options

  • AWS Servers: Data is uploaded, stored, and managed on Amazon Web Services (AWS) cloud servers, which are ISO/IEC 27001 certified, ensuring secure data processing.

  • Private Servers: FlightHub 2 supports both public and private cloud servers, offering flexible deployment based on user requirements. An on-premises version will be available soon.

Custom Permission Management

FlightHub 2 allows users to configure management permissions, ensuring access is tailored to operational needs.

User-Controlled Data Sharing

  • Users must opt-in to share photos and videos with DJI.

  • Personal data used for account registration is protected with AES-256 encryption.

  • Operators can delete shared data via their DJI account for full control over their information.

Conclusion

DJI Dock 3 revolutionises remote drone operations with faster deployment, enhanced weather resistance, and seamless integration with FlightHub 2 for mission planning and data management.

For expert guidance on how DJI Dock 3 can benefit your organisation, contact heliguy™. Our team is ready to assist with any queries and provide tailored drone solutions.
