DJI drone payload compatibility and maximum payload capacity guide
An in-depth breakdown of DJI drone payload compatibility, highlighting supported sensors, accessories, and maximum payload capacities across the DJI enterprise range.
Find out which DJI payloads work with leading drones like the M400, M350 RTK, and M300 RTK
See how much weight each model can carry — from the FlyCart 30’s 40 kg lift to the Mavic 3 Thermal’s 130 g limit
Learn which aircraft support specialist sensors such as the Sniffer4D gas detection systems and Soarability MetScan methane scanner
Discover compatible accessories like the CZI LP12 and LP35 searchlights, Zenmuse S1 searchlight, and V1 voice speaker
Compare payload support for DJI Dock-enabled drones including the Matrice 3D and 4D Series
Get quick, clear insight into which DJI drone is best suited for inspection, mapping, delivery, or environmental monitoring
Understanding which DJI payloads work with each drone is essential for choosing the right aircraft for your operations.
From mapping and surveying to inspection, delivery, and gas detection, DJI offers a wide range of compatible payloads — each designed to optimise data capture and mission performance.
This guide explains which payloads are compatible with key DJI enterprise drones and outlines their maximum payload capacity to help you select the right platform for your needs.
DJI drone payload compatibility and maximum payload capacity comparison table
Use this table to quickly identify which payloads and accessories each drone supports — including sensors, searchlights, speakers, and gas detection systems — and how much additional weight each model can safely carry.
Model | Compatible payloads | Max payload capacity |
DJI FlyCart 30 | Cargo box or winch system | 30 kg (with dual battery) / 40 kg (with a single battery) |
DJI Matrice 400 | Zenmuse H30/H30T, H20 Series (H20/H20T/H20N), L2, P1, S1 Searchlight, V1 Voice Speaker, and Soarability MetScan V1 Methane Scanning System. | 6 kg |
DJI Matrice 350 RTK | Zenmuse H30/H30T, H20 Series (H20/H20T/H20N), L2, P1, S1 Searchlight, V1 Voice Speaker, CZI LP35 Searchlight and Broadcasting System, Soarability MetScan V1 Methane Scanning System, Share UAV 203S PRO, Sniffer4D Mini2 Gas Detection System. | 2.7 kg |
DJI Matrice 300 RTK | H20 Series (H20/H20T/H20N), L1, P1, S1 Searchlight, V1 Voice Speaker, Soarability MetScan V1 Methane Scanning System, Share UAV 203S PRO, Sniffer4D Mini2 Gas Detection System. | 2.7 kg |
DJI Matrice 30 Series | CZI LP12 Searchlight and Speaker, Sniffer4D Mini2 Gas Detection System. | 0.3 kg (228 g payload capacity, if operating under C2 certification limits (EU) ) |
DJI Matrice 4 Series | AL1 Spotlight, AS1 Speaker, DJI Manifold 3, and Matrice 4 Obstacle Sensing Module. | 200 g |
DJI Matrice 4D Series | Matrice 4 Obstacle Sensing Module, Sniffer4D Nano2+ Methane TDLAS Sensing and Mapping System (for DJI Dock 3). | 240 g |
DJI Matrice 3D Series | Sniffer4D Nano2 TDLAS Methane Detection (for DJI Dock 2). | 200 g |
DJI Mavic 3 Thermal | Sniffer4D Mini2 Gas Detection System. | 130 g |
DJI Mavic 3 Enterprise | Sniffer4D Mini2 Gas Detection System. | 135 g |
Get in touch
For expert advice on selecting and integrating DJI payloads, contact the Heliguy team.
We’ll help you choose the right equipment for your operations and provide ongoing support through our DJI-certified drone repair centre.
DJI Drone Payload Compatibility FAQs
Which DJI drone can carry the heaviest payload?
The DJI FlyCart 30 has the highest payload capacity in DJI’s range, carrying up to 40 kg with a single battery or 30 kg with dual batteries. It’s designed for aerial delivery and heavy-lift operations.
Which DJI drones are compatible with the Sniffer4D Gas Detection Systems?
The Sniffer4D Mini2 is compatible with the DJI M350 RTK, M300 RTK, M30 Series, Mavic 3 Enterprise, and Mavic 3 Thermal.
The Sniffer4D Nano2 and Nano2+ versions are designed for the DJI Dock 2, Dock 3, and Matrice 3D/4D Series.
Can I use the same payloads on the M300 RTK and M350 RTK?
Yes. The DJI M350 RTK and M300 RTK share similar architectures, supporting the same payloads, including the H20 Series, L1, P1, S1 Searchlight, and V1 Speaker, along with compatible third-party options.
Do all DJI drones support external payloads?
No. Some drones, such as the Mavic 3 Enterprise and Matrice 30 Series, have limited payload capacity and are mainly compatible with lightweight accessories or specific third-party sensors.
Which DJI drones are compatible with DJI Dock systems?
The Matrice 3D/3TD are designed for the DJI Dock 2, while the Matrice 4D Series works with the DJI Dock 3, enabling fully automated, remote operations.
How do I choose the right DJI payload for my work?
Use the table below to help you decide which is the right payload for your operations.
Application | Recommended DJI Payloads |
Inspection and Mapping | Zenmuse P1, Zenmuse L2, Zenmuse H20 Series |
Public Safety | S1 Searchlight, V1 Speaker, CZI LP35 |
Environmental Monitoring | Sniffer4D, Soarability MetScan systems |
Delivery | FlyCart 30 with cargo box or winch |
