DJI Inspire 3 First Flight Guide

heliguy™ covers how to activate the batteries, mount the camera, link the controller, and update firmware.

  • This guide provides step-by-step instructions for preparing and completing your first flight with the DJI Inspire 3, including:

  • How to activate the TB51 intelligent batteries and install them securely on the aircraft;

  • The process of mounting the DJI Pro SSD, camera lens, and Zenmuse X9 8K gimbal camera;

  • How to activate and link the DJI Inspire 3 and the DJI RC Plus remote controller using the DJI Pilot 2 app;

  • Instructions for switching between travel mode and landing mode for proper setup;

  • Firmware updates to ensure the aircraft and remote controller are up to date;

  • Guidance on installing propellers, transferring footage, and properly storing your equipment post-flight.

Learn how to set up and operate your DJI Inspire 3 with ease. From activating batteries and mounting the camera to linking the remote controller and updating firmware, this guide covers everything you need for a seamless first flight.

You’ll also find instructions for installing propellers, transitioning between travel and landing modes, and managing post-flight storage. Follow these steps to get your DJI Inspire 3 ready for cinematic-grade aerial shooting.

Activating the TB51 Intelligent Battery

  1. Charge the batteries: Insert the AC power cable into the charging hub, open the battery covers, and insert the TB51 batteries.

  2. Set the charging mode:

    1. Fast Mode: Charges two batteries to 90% in 35 minutes.

    2. Standard Mode: Charges one pair to 100% in 55 minutes.

    3. Silent Mode: Charges two batteries to 100% in 80 minutes with reduced fan noise.

  3. Check charging status: The LED indicates progress and turns solid green when fully charged.

Installing the batteries

  1. Prepare the aircraft: Remove protective covers from the battery compartment.

  2. Insert the batteries: Insert two fully charged TB51 batteries until you hear a click, confirming secure installation.

Mounting the DJI Pro SSD

Install the SSD:

  1. Open the SSD slot cover.

  2. Insert the DJI Pro SSD and ensure the indicator lights up to confirm proper installation.

Travel Mode

Switch to landing mode: Press the power button five times to transform the aircraft from travel mode to landing mode.

Mounting the camera lens

Secure the lens:

  1. Rotate the lens lock lever counterclockwise to unlock.

  2. Align the red marks on the lens and mount.

  3. Insert and rotate the lens clockwise to secure the lens in place.

Mounting the gimbal camera

Attach the gimbal:

  1. Press the gimbal release button and remove the cap.

  2. Align the gimbal lock with the red dot on the mounting point.

  3. Mount securely by ensuring proper alignment.

DJI RC Plus Remote Controller

Remote controller features:

  1. Use the aircraft control button to manage connection status.

  2. Press and hold the RTH button to initiate or cancel Return-to-Home.

  3. Check status and battery level LEDs for device information.

  4. Use the 5D button for customizable shortcuts.

  5. Adjust the gimbal tilt and pan with the left and right dials.

  6. Switch flight modes (S, N, F) using the flight mode switch.

  7. Insert a microSD card or connect external devices via USB or HDMI ports.

Aircraft activation and linking

Activate and link:

  1. Run the DJI Pilot 2 app on the remote controller.

  2. Follow the on-screen prompts to activate the aircraft and link it to the remote controller.

Firmware update

Update firmware: Use DJI Pilot 2 to check for and install firmware updates for the aircraft and remote controller.

Propeller Installation

Attach the propellers:

  1. Match the marked propellers to the corresponding motors.

  2. Press the propellers down firmly and rotate until locked securely in place.

Post-flight procedures

  1. Transfer footage: Use the provided USB-C to USB-C cable to transfer footage.

  2. Disassemble components:

    1. Remove the gimbal camera and store it in its case.

    2. Use the app or press the power button five times to switch to travel mode.

  3. Pack the equipment:

    1. Align the folded propellers with the aircraft arms before storage.

    2. Place all components, including batteries, cables, and the remote controller, into the trolley case.

Summary

Completing your first flight with the DJI Inspire 3 is straightforward with the steps outlined in this guide.

From activating the batteries and installing key components to mastering in-flight controls and post-flight procedures, you’re now equipped to operate your aircraft with confidence. Proper maintenance and secure storage ensure your equipment stays in excellent condition for future use.

For additional support or assistance, contact heliguy™.
