How to Use the DJI Inspire 3 Controller: RC Plus Guide
Learn gestures, shortcuts, button customisation, HDMI output, and compass calibration.
This guide explains the user interface of the DJI RC Plus remote controller and its key features;
Provides instructions for navigating the screen using intuitive gestures for efficient operation; Details how to access and use Shortcut Settings for quick adjustments like Wi-Fi, Bluetooth, and screen brightness;
Covers HDMI settings for connecting to external displays and sharing the camera view;
Lists combination button shortcuts for frequently used functions like screen recording and brightness control;
Includes steps for compass calibration to ensure accurate flight in areas with electromagnetic interference;
Ensures you can confidently manage your Inspire 3 with the DJI RC Plus remote controller for professional aerial operations.
The DJI RC Plus Remote Controller is a versatile tool designed to give you full control of your Inspire 3. With its intuitive user interface, advanced shortcut settings, and practical features like HDMI output and compass calibration, the controller ensures a seamless and professional flying experience.
Whether you're navigating the screen gestures, customising button combinations, or managing system settings, this guide will help you unlock the full potential of the DJI RC Plus for efficient and precise aerial operations.
Accessing the system interface
Power on the remote controller to view the home screen.
The top bar displays essential information, including time, Wi-Fi signal, and battery level.
The bottom bar provides access to key features (in the table below).
Feature | Overview |
|---|---|
DJI Pilot 2 App | Main application for controlling the Inspire 3. |
Gallery | View stored photos and videos. |
File | Check stored files on the remote controller. |
Firefox Browser | Access the internet. |
Settings | Adjust system settings. |
Tips | Get detailed information on buttons and LED indicators. |
Screen gestures
Navigation gestures:
Slide from the left or right to the centre of the screen to return to the previous screen.
Slide up from the bottom to return to the home screen.
Slide up from the bottom and hold to access recently opened apps.
Shortcut settings
Accessing shortcut settings: Slide down from the top of the screen to reveal Shortcut Settings.
Available options | Overview |
|---|---|
Notifications | View system alerts and notifications. |
Recent | Access and switch between recently opened apps. |
Home | Return to the home screen. |
System Settings | Open system settings. |
Wi-Fi | Enable/disable Wi-Fi or access network settings. |
Bluetooth | Enable/disable Bluetooth or connect to nearby devices. |
Do Not Disturb Mode | Mute system prompts and alerts. |
Display Enhancement | Boost screen brightness for shooting (does not affect captured media). |
Screen Recording | Start recording the screen. |
Screenshot | Capture a screenshot. |
Mobile Data | Enable/disable mobile data or diagnose network issues. |
Airplane Mode | Disable Wi-Fi, Bluetooth, and mobile data. |
Brightness | Adjust brightness manually or toggle auto mode. |
Volume | Adjust or mute the system volume. |
HDMI Settings
Connecting to a display:
Connect the HDMI port of the remote controller to an external display using an HDMI cable.
Set the resolution in the DJI Pilot 2 app to share the camera view on the external display.
Frequently used shortcuts
Back Button + Left Dial: Adjust screen brightness.
Back Button + Right Dial: Adjust volume.
Back Button + Record Button: Start screen recording.
Back Button + Shutter Button: Capture a screenshot.
Back Button + 5D Button:
Toggle up to access the home screen.
Toggle down to open Shortcut Settings.
Toggle left to view recently opened apps.
Compass Calibration
When calibration is needed: The remote controller may prompt calibration after use in areas with electromagnetic interference.
Steps to calibrate the compass:
Power on the remote controller and access the home screen.
Enter "Settings" and select "Compass".
Follow the on-screen instructions to complete the calibration process.
A success prompt will appear upon completion.
Summary
The DJI RC Plus Remote Controller offers an intuitive interface and powerful features to seamlessly operate your Inspire 3. By following this guide, you can effectively navigate the system, utilise shortcuts, configure HDMI settings, and calibrate the compass when needed.
With these tools, you’re equipped for a smooth and efficient aerial operation. For further assistance or inquiries, contact heliguy™.
