DJI Agras T25

Precision Agriculture In A Portable Package

DJI Agras T25 packs all of the advanced features of the Agras T50 into a smaller, more portable design.

It can carry a 20kg spraying or 25kg spreading payload.

DJI Agras T25 is equipped with multidirectional obstacle avoidance, Terrain Following, one-tap take-off, and automatic operations.

The drone is compatible with the DJI SmartFarm app, dedicated to agricultural drone operations.

The design of Agras T25 makes it perfect for solo use in small to medium-sized farms.

DJI Agras T25 Key Features

  • Carry 20kg spraying or 25kg spreading payload.
  • Dual atomised spraying system for adjustable droplet sizes and high flow rates.
  • Four-sprinkler configuration: Equip with an extra pair of centrifugal sprinklers to further increase flow rates.
  • Dual radar and dual binocular vision for obstacle bypassing and terrain following.
  • Upgraded four-antenna O3 Transmission system.
  • UHD FPV gimbal camera.
  • Fixed-altitude flight over 50° slopes.
  • Corrosion resistant.
  • 1500 battery cycles.
  • Aerial survey/mapping.
  • Compatible with DJI Smart Farm.
  • Robust data security protocols.

DJI SmartFarm

The DJI SmartFarm app streamlines daily drone operations for crop protection and plot management.

It features enhanced data visualisation and reporting, and a dynamic device management dashboard.

Benefit from end-to-end service support for spraying and spreading operations, including field sharing, tutorials, team collaborations, and measurement tools.

With the app, you can view data clearly on your Agras drones while controlling and managing your device with superior ease and efficiency.

Robust Data Security

No flight logs, photos, or videos are synced with DJI by default.

DJI Agras drones are designed to store data locally in the remote control and the drone. Operators must opt-in to share or store their data on DJI servers.

For users outside of the Chinese mainland, drone data shared with DJI are
housed in U.S., Japan, and European servers (depending on where the user is
based) and TLS-protected.

Any personal data shared for account registration is further secured with AES-256 encryption.

Operators can easily delete any data they have shared through their DJI account or by contacting DJI Support.

Product specification

DJI Agras T25

Specification Value
Weight 24.4 kg (excluding the battery)
32 kg (including the battery)
Maximum Takeoff Weight Maximum takeoff weight for spraying: 52 kg (at sea level)
Maximum takeoff weight for spreading: 58 kg (at sea level)
Maximum Diagonal Wheelbase 1925 mm
Dimensions 2585×2675×780 mm (arms and propellers unfolded)
1475×1540×780 mm (arms unfolded and propellers folded)
1050×690×820 mm (arms and propellers folded)
Hovering Accuracy Range (with strong GNSS signal) D-RTK enabled:
Horizontal: ±10 cm
Vertical: ±10 cm
D-RTK disabled:
Horizontal: ±60 cm
Vertical: ±30 cm (radar module enabled: ±10 cm)
RTK/GNSSOperating Frequency RTK:
GPS L1/L2, GLONASS F1/F2, BeiDou B1I/B2I/B3I, Galieo E1/E5b, QZSS L1/L2
GPS L1, BeiDou B1I, GLONASS F1, Galieo E1, QZSS L1
Maximum Configurable Flight Radius 2000 m
Maximum Wind Resistance 6 m/s
Propulsion System - Motors
Stator Size 100×28 mm
KV 59 rpm/V
Power 4600 W/rotor
Propulsion System - Propellers
Material Nylon carbon fiber filament
Dimension 50 inch
Propeller Rotation Diameter 1270 mm
Quantity 4
Dual Atomising Spraying System - Spray Tank
Material Plastic (HDPE)
Volume 20 L
Operating Payload 20 kg
Quantity 1
Dual Atomising Spraying System - Sprinklers
Model LX8060SZ
Quantity 2
Nozzle Distance 1368 mm(Rear Nozzles)
Droplet Size 50 - 500 up
Effective Spray Width 4-7 m (at a height of 3 m above the crops)
Dual Atomising Spraying System - Delivery Pumps
Type Impeller pump (magnetic drive)
Quantity 2
Single Pump Flow Rate 0-12 L/min
Maximum Flow Rate 16 L/min (2 sprinklers) 24 L/min (4 sprinklers)
DJI AGRAS T25 Spreading System
Compatible Material Diameter 0.5-5 mm
Spread Tank Volume 35 L
Spread Tank Internal Load 25 kg
Effective Spraying Width Varies according to material diameter, spinner disk rotational speed, hopper outlet size, and flight altitude. For optimal performance, it is recommended to adjust the corresponding variables to achieve a spreading range of 5-8 meters.
Phased Array Radar System
Model RD241608RF (forward phased array radar)
RD241608RB (rear phased array radar)
Terrain Follow Max slope in Mountain mode: 20°
Altitude detection range: 1-50 m
Stabilisation working range: 1.5-30 m
Obstacle Avoidance Obstacle sensing range (omnidirectional): 1-50 m FOV: Forward phased array radar: horizontal 360°, vertical ±45°, upward ±45° (cone)
Rear phased array radar: vertical 360°, horizontal ±45°
Working conditions: flying higher than 1.5 m over the obstacle at a horizontal speed no more than 10 m/s and vertical speed no more than 3 m/s.
Safety limit distance: 2.5 m (distance between the front of propellers and the obstacle after braking)
Sensing direction: 360° omnidirectional sensing
Binocular Vision System
Measurement range 0.5-29 m
Effective Sensing Speed ≤10 m/s
FOV Horizontal: 90°
Vertical: 106°
Operating Environment Adequate light and discernible surroundings.
Remote Controller
Model RM700B
Operating Frequency 2.4000-2.4835 GHz, 5.725-5.850 GHz
Maximum Transmission Distance 7 km (FCC), 5 km (SRRC)
4 km (MIC/CE)
(unobstructed, free of interference, and at an altitude of 2.5 m)
Wi-Fi Protocol Wi-Fi 6
Wi-Fi Operating Frequency 2.4000-2.4835 GHz
5.150-5.250 GHz
5.725-5.850 GHz
Bluetooth Protocol Bluetooth 5.1
GNSS GPS+Galileo+BeiDou
Screen 7.02-in LCD touchscreen, with a resolution of 1920×1200 pixels, and high brightness of 1200 cd/m2
Operating Temprature -20° to 50° C (-4° to 122° F)
Storage Temperature Range Less than one month: -30° to 45° C (-22° to 113° F)
One to three months: -30° to 35° C (-22° to 95° F)
Six months to one year: -30° to 30° C (-22° to 86° F)
Charging Temperature 5° to 40° C (41° to 104° F)
Internal Battery Runtime 3 hours 18 minutes
External Battery Runtime 2 hours 42 minutes
Charging Type It is recommended to use a locally certified USB-C charger at a maximum rated power of 65 W and a maximum voltage of 20 V such as the DJI 65W Portable Charger.
Charging Time 2 hours for internal battery or internal and external battery (when remote controller is powered off and using a standard DJI charger)
DB800 Intelligent Flight Battery
Model DB800 Intelligent Flight Battery
Weight Approximately 6.6 kg
Capacity 15000 mAh
Nominal Voltage 52.22 V
C8000 Intelligent Charger
Model Number CSX702-9500
Dimensions 400 × 266 × 120 mm
Weight Approximately 11.4 kg
Input / Output Input Voltage: 100-240 VAC
Output Voltage: 59.92V
Output Current: 100A maximum
Charging Time Fully charges a battery in 9 to 12 minutes (DB800 Intelligent Flight Battery)
Protection Functions Over-temperature, over-voltage, under-voltage, short-circuit, and fan stall protection
Charging Safety AC wire protection, power wire protection, and charge connector protection
Model RL01-65
Dimensions 120×110×100 mm
Weight ≤575 g
Input Voltage 9 V3 A / 12 V2.5 A / 15 V2 A
Power Consumption 9 W (SRRC), 12 W (FCC)
Capacity 6500 mAh
Operating Time 4 hours
Operating Frequency 2.4000-2.4835 GHz
5.725-5.850 GHz
Maximum Transmission Distance 5 km (SRRC), 4 km (MIC/KCC/CE), 7 km (FCC)
(unobstructed, free of interference, and at a flight altitude of 2.5 m)
Charging Time 2 hours and 20 minutes (when using a standard DJI charger)
IP Rating IP55

What's in the Box

DJI Agras T25

Aircraft x 1
Tool Box x 1
Remote controller x 1
Remote controller strap x 1
USB-C Cable x 1
Screws and other accessories
