Question 1

What functions does the DJI AL2D Spotlight support?

Accepted Answer

The DJI AL2D Spotlight supports four lighting modes: Floodlight, Spotlight, Both On, and Auto. It also supports two alert modes: Fast Strobe and Slow Strobe, and allows gimbal follow to be enabled or disabled.

Question 2

What are the differences between the DJI AL2D Spotlight and the DJI AL1 Spotlight?

Accepted Answer

The core differences between the DJI AL2D Spotlight and the DJI AL1 Spotlight are: The brightness has been significantly increased to 2.6 times that of the previous generation. A new dual-lens high-brightness spotlight has been added, supporting both spotlight and floodlight modes. Upward illumination is supported at angles up to +90°.

Question 3

Which aircraft are compatible with the DJI AL2D Spotlight?

Accepted Answer

The DJI AL2D Spotlight is compatible only with the DJI Matrice 5TD aircraft.

Question 4

What precautions should be taken when installing the DJI AL2D Spotlight?

Accepted Answer

The following precautions should be taken when installing the DJI AL2D Spotlight: Install the spotlight on the right side of the aircraft using the Matrice 5TD accessory mount, and make sure the mounting screws are securely tightened. Install the spotlight before powering on the aircraft. Do not install the spotlight while the aircraft is powered on. Make sure the plug is securely inserted. Do not pull the cable with excessive force, as this may compromise water resistance or cause damage. Tighten the connector screws properly. Do not overtighten them, as this may cause damage. After installation, connect to the internet and follow the prompts to activate the spotlight. If prompted to update the firmware, update it promptly to the latest version.

Question 5

What precautions should be taken when using the DJI AL2D Spotlight?

Accepted Answer

The following precautions should be taken when using the DJI AL2D Spotlight: After the spotlight is installed, the aircraft's propulsion performance and flight endurance will be affected. When the spotlight is turned on, visual obstacle sensing is disabled and only the mmWave radar and LiDAR remain active, reducing omnidirectional obstacle sensing performance. Fly with caution. DO NOT point the spotlight directly at anyone’s eyes, as this may cause eye injury. The spotlight may become hot after prolonged operation. Avoid touching it to prevent burns.

Question 6

What are the tips for using the DJI AL2D Spotlight?

Accepted Answer

When using the DJI AL2D Spotlight during high-altitude flights, water vapour and suspended particles in the atmosphere may make the image appear washed out. It is recommended to enable the electronic defogging function for better image quality. To minimise the impact on the aircraft's flight endurance, reduce the spotlight brightness as appropriate and turn it on only when needed.

Question 7

Does the DJI AL2D Spotlight support disabling gimbal follow function?

Accepted Answer

Yes, in the spotlight settings, you can choose to disable the gimbal follow function on the DJI AL2D Spotlight. Please note that once disabled, the spotlight will maintain its current angle; when re-enabled, the spotlight will automatically adjust to align with the gimbal's orientation. The gimbal follow function will remain enabled by default after the aircraft restarts.

Question 8

How do I update the firmware of the DJI AL2D Spotlight?

Accepted Answer

After the DJI AL2D Spotlight is installed on the aircraft, its firmware will be updated together with the aircraft firmware. The firmware can be updated in either of the following ways: 1. Perform a one-click update on the Device Management page in DJI FlightHub 2. 2. Connect the aircraft to a computer and update it using DJI Assistant 2 (Enterprise Series).

Question 9

What is the IP rating of the DJI AL2D Spotlight?

Accepted Answer

The DJI AL2D Spotlight has an IP55 rating.
