DJI M350: First Flight Guide

Step-by-step guide to your first DJI M350 RTK flight: setup, controls, and storage.

  • This guide provides step-by-step instructions for completing your first flight with the DJI M350 RTK;

  • How to assemble the aircraft, including attaching the landing gear, propellers, and gimbal;

  • The activation process for the remote controller and aircraft using the DJI Pilot 2 app;

  • Preflight preparations for safe and efficient operation;

  • Instructions for manual takeoff, in-flight controls, and landing procedures;

  • Camera operations, such as switching modes, zooming, and gimbal adjustments;

  • The process for hot-swapping batteries to maintain operational efficiency during flights;

  • Guidance on powering off and properly storing the aircraft and accessories after use.

From assembling the aircraft and activating the remote controller to mastering in-flight controls and performing safe landings, this guide ensures a smooth and efficient experience.

Learn how to operate the camera, replace batteries mid-flight, and store your equipment properly to keep your DJI M350 RTK in top condition. Follow these instructions to confidently take to the skies with your new drone.

Assembly

  1. Set up the landing gear: Open the carrying case and insert the landing gear into the connector on the aircraft. Then slide and rotate the gear lock clockwise to secure it in the locked position.

  2. Unfold the frame arms:

    1. Remove the aircraft from the carrying case and unfold the frame arms.

    2. Rotate each frame arm to the locked position and secure the arm lock by sliding and rotating it clockwise.

    3. Ensure the frame arms are firmly mounted.

  3. Unfold the Propellers.

  4. Prepare the gimbal: Install the gimbal and camera (e.g., Zenmuse H20T):

    1. Align the white dot on the gimbal with the red dot on the gimbal connector.

    2. Rotate the gimbal lock to the locked position.

    3. Remove the camera cap.

Install the batteries: Insert the batteries into the aircraft and rotate the battery release toggle by 90° until it clicks into place.

Activating the Remote Controller Battery

  1. Charge the battery: Connect the remote controller to the battery station using a USB-C to USB-C cable and charge it to awaken the controller.

  2. Power on the controller: Press and hold the power button for three seconds to turn on the remote controller.

  3. Activate the remote controller: Follow the on-screen prompts in the app to complete the activation process.

Device Activation

  1. Power on the devices: Press the power button on both the remote controller and aircraft once, then hold it for three seconds to turn them on.

  2. Activate in the app:

    1. Open the DJI Pilot 2 app, where the activation page will appear automatically.

    2. Read and accept the terms, authorise device information usage, select a usage scenario, and tap "Activate".

    3. Tap "Restart Now"to complete activation

First Flight

  1. Prepare for flight: Open the DJI Pilot 2 app and tap "Enter Camera View", and complete the preflight checklist displayed in the app.

  2. Set up the remote controller: Unfold and adjust the antenna for optimal communication range.

  3. Takeoff:

    1. Maintain a safe distance of at least 5 metres from the aircraft.

    2. Start the motors by pushing the left and right control sticks to the inner or outer bottom corners.

    3. Once the propellers start spinning, gently push the throttle stick up to take off manually.

  4. In-flight controls:

    1. Use the left stick to adjust flight altitude and rotate the aircraft.

    2. Use the right stick to control forward, backward, leftward, and rightward movements.

  5. Landing: Pull the left stick down to land manually. Continue holding it until the motors stop.

Camera operations

  1. Tap the Shutter/Record button to switch between photo and video modes.

  2. Adjust the gimbal pitch and yaw angles using the left and right dials.

  3. Switch between infrared, wide-angle, and zoom cameras using L1 and L2 buttons.

  4. Zoom in and out with the zoom camera using R1 and R2 buttons.

  5. Double-tap a target point to align the gimbal and camera.

Additional features:

  • Enable the laser ranging function by tapping the laser ranging icon.

  • Use the infrared mode to measure temperatures or set a high-temperature alarm.

Flight Pause and RTH

  1. Pause the flight: Press the flight pause button to make the aircraft hover in place.

  2. Activate RTH: Press and hold the RTH button on the remote controller to initiate the Return to Home function.

Hot Battery Replacement

Replace the battery without shutting down:

  1. Unlock the battery release toggle and remove one battery.

  2. Insert a backup battery and ensure the battery indicator lights up.

  3. Replace the second battery following the same process.

Power Off and Storage

  1. Power off the aircraft: Press and hold the power button on the aircraft to turn it off.

  2. Remove and store the batteries: Rotate the battery release toggle to remove the batteries and store them safely.

  3. Detach and store the gimbal: Align the gimbal axis arm with the DJI logo and place it in the carrying case.

  4. Prepare the aircraft for storage:

    1. Fold the frame arms and propellers parallel to the aircraft body to avoid damage.

    2. Place the aircraft and all accessories securely in the carrying case.

  5. Store the remote controller: Power off the remote controller, fold the antennas, and place it in the carrying case.

Summary

Completing your first flight with the DJI M350 RTK is straightforward thanks to the detailed steps in this guide. From assembly and activation to in-flight controls and storage, you now have the knowledge to operate your aircraft safely and effectively.

Following these instructions ensures a smooth flight experience and proper maintenance for your equipment. For further assistance or questions, don’t hesitate to contact heliguy™.
