DJI Mavic 3 Pro: Tri-Camera System Explained
Learn autofocus, zoom, colour modes, & encoding for pro-level shots.
Discover the advanced camera system of the DJI Mavic 3 Pro, featuring a Hasselblad camera and dual telephoto lenses.
Learn how to switch between Auto and Manual focus for greater control over image sharpness.
Adjust camera parameters in Auto and Pro modes, including white balance, shutter speed, aperture, and ISO.
Use Auto Exposure (AE) settings to maintain consistent lighting and prevent overexposure.
Explore the zoom capabilities of each camera, ranging from 1x to 28x digital zoom for flexible framing.
Enable 1080p/60fps video transmission for smooth, high-quality real-time viewing.
Quickly switch camera views by double-tapping on your target subject.
Understand video encoding formats, including H.264, H.265, and Apple ProRes for professional workflows.
Make the most of D-Log M and HLG colour modes for a wider dynamic range and improved colour grading options.
Use Colour Display Assist to preview footage with enhanced contrast for better composition and focusing.
The DJI Mavic 3 Pro features a tri-camera system, including a Hasselblad camera and dual telephoto cameras, offering advanced capabilities for professional and creative aerial photography.
This guide explains key camera functions, from autofocus and manual focus to zoom, colour modes, and encoding formats, helping you make the most of your drone’s imaging system.
Auto and Manual Focus
The default setting is auto focus (AF), which automatically adjusts focus based on the subject’s distance for sharp images.
If AF is insufficient, switch to manual focus (MF) for precise control.
Tap the "AF" icon in the DJI Fly app’s live view, then drag the parameter bar to manually adjust focus.
Adjusting camera parameters
Tap any displayed parameter to access detailed settings.
Auto mode: Displays limited parameters and allows quick adjustments to the storage path, video format, and exposure value (EV).
Pro mode: Provides full control over settings such as white balance, shutter speed, aperture, and ISO.
Using Auto Exposure (AE)
When in auto mode, tap the camera view to activate the metering box.
Adjust EV by dragging the sun icon up or down.
Tap and hold the metering box to enable AE lock, which maintains consistent exposure.
Disable AE lock by tapping another area of the screen or manually adjusting EV.
Camera zoom capabilities
Check out the table below to learn about the digital zoom capabilities of all three lenses.
Digital zoom | Lens |
|---|---|
1x-3x digital zoom | Hasselblad camera (24mm format equivalent). |
3x-7x digital zoom | Medium telephoto camera (70mm format equivalent). |
7x-28x digital zoom | Telephoto camera (166mm format equivalent). |
Zoom controls:
Tap 1x, 3x, or 7x on the right side of the screen.
Tap and hold the zoom button, then drag up/down.
Use two fingers to pinch zoom on the screen.
Adjust zoom using the camera control dial on the remote controller.
Explore Mode: Allows continuous zoom adjustments in normal photo or video mode.
60fps video transmission
Supports 1080p/60fps video transmission for smoother control and near-recorded quality.
In normal photo mode, 1080p/60fps is enabled by default.
When recording:
60fps or higher: Transmission automatically switches to 1080p/60fps.
Below 60fps: Transmission defaults to 1080p/30fps.
Quick camera view switching
Tap twice on the target view to automatically centre the camera on the subject.
Video encoding formats
DJI Mavic 3 Pro supports: H.264 and H.265 encoding.
Mavic 3 Pro Cine cameras also support: Apple ProRes 422 HQ, Apple ProRes 422, and Apple ProRes 422 LT.
To record in Apple ProRes, set the video resolution to 4K or higher, then select "ProRes" in the app’s "Coding Format" settings.
Colour Modes
Hasselblad camera and medium telephoto camera support D-Log M and HLG for an extended dynamic range.
Hasselblad camera offers D-Log mode, enabling greater flexibility in post-production.
Colour Display Assist can be activated to preview a more natural colour contrast for improved composition and focusing.
Summary
The DJI Mavic 3 Pro’s advanced camera system provides powerful tools for professional and creative aerial photography. Whether adjusting focus, exploring zoom options, or fine-tuning colour settings, these functions offer enhanced flexibility and control over your footage.
Experiment with these features to refine your shooting style and achieve outstanding cinematic results. For further assistance, contact heliguy™.
