DJI RC Pro First Use Guide

A complete walkthrough for setting up, activating, updating, and operating the DJI RC Pro 2 remote controller.

This support guide covers:

  • Powering on and off the DJI RC Pro 2 controller

  • Activation steps, Wi-Fi setup, and account login

  • Updating firmware and linking the controller to the aircraft

  • Using sleep mode and adjusting screen timeout settings

  • Button functions, flight modes, and using the DJI Simulator

This guide explains how to set up and use the DJI RC Pro 2 controller. It covers powering on, activation, firmware updates, linking to the aircraft, button functions, and more.

Follow each step to get your controller ready for safe and efficient flying.

Instructions

1. Powering On / Off

  • Unfold the antennas downward.

  • Extend the screen arm to power on the controller.

  • To power off: press the power button once, then press and hold it for two seconds.

2. Activation

  • On first power-up, select your language and region.

  • Connect the controller to a Wi-Fi network.

  • Set the time zone, date, and time.

  • Log in with your DJI Account (new users must register).

  • After activation, tap Start to enter the function guide.

  • If the status LED blinks cyan, the control stick isn’t centred. Launch the DJI Fly App and follow the prompts to calibrate.

3. Firmware Update

  • If a firmware update is available, a prompt will appear.

  • Tap the prompt to enter the update screen, then tap Update.

  • Make sure the controller is charged to at least 20% before updating.

  • Do not exit the DJI Fly app or disconnect from the internet during the update.

  • The controller will automatically restart once the update is complete.

4. Linking the Remote Controller

If purchased as a combo with the aircraft (Mavic 4 Pro Creator Combo) the controller is already linked.

If not, tap Linking Guide in the bottom-right corner of DJI Fly and follow the instructions:

  • When the controller beeps and its status indicator flashes blue, start linking.

  • Press and hold the aircraft power button for 4 seconds, then release after the tone.

  • A moving icon on the aircraft’s power indicator confirms linking has begun.

  • Once the controller light turns solid green and the aircraft displays battery level, linking is successful.

If linking fails:

Use DJI Assistant 2 (Consumer Drone Series) on a computer to update both devices before trying again.

5. Sleep Mode

  • Fold the arm or press the power button to turn off the screen.

  • The controller enters sleep mode after the screen is off for a short period; status LED pulses blue.

  • While asleep, the controller disconnects to save power.

  • Extend the arm or press the power button to wake it and restore the connection.

  • If not woken within 1 hour, it powers off automatically.

  • Go to Settings > Display to adjust screen timeout.

6. Button Features

  • Focus/Shutter Button: Half-press to autofocus, full-press to take a photo.

  • Record Button: Press once to start or stop recording.

  • Left Dial: Adjust gimbal tilt.

  • Right Dial: Zoom in/out by default (can be customised to control roll axis).

  • Camera Modes: Rotate the screen to switch between landscape and portrait.

Mode

Explanation

AUTO

Rotate dial to adjust EV

PRO

Press the dial to change settings, rotate to adjust.

  • During Playback: Rotate the dial to move selection box. Press to preview. Press and hold to select multiple items.

  • Back Button: Return to previous screen.

  • Flight Mode Switch: Toggle between Cine, Normal, and Sport.

  • RTH Button: Press once to brake and hover. Press and hold to activate Return to Home and land.

  • C1, C2, and 5D Buttons: Customisable via DJI Fly app.

7. Signal and Flight Awareness

During flight, maintain a clear and stable signal by adjusting the position and distance between the aircraft and remote controller.

8. DJI Simulator

For first-time flyers, use the DJI Simulator to practise flying safely before actual flight.

Summary

We've walked you through the essential steps to set up, activate, and operate your DJI RC Pro 2 controller.

From powering on and linking to your aircraft, to using button functions, sleep mode, and the DJI Simulator, you're now ready to control your drone confidently.

Always ensure your firmware is updated and follow setup instructions for a smooth and reliable flight experience.
