DJI Mavic 4 Pro: First Use Tutorial with RC Pro 2

This tutorial covers...

• Setting up the aircraft and activating the battery

• Powering on and configuring the DJI RC Pro 2 controller

• Activating the drone and updating firmware via DJI Fly

• Performing takeoff, flight controls, and landing

• Using camera features and Return to Home functions

We'll walk you through setting up and flying your DJI Mavic 4 Pro using the RC Pro 2 controller.

It covers everything from powering on and activating the drone to basic flight controls, camera functions, and safe landing procedures. Follow each step to ensure a smooth and successful first flight.

Steps to follow

1. Prepare the Aircraft

• Unfasten the strap and remove the gimbal protector.

• Press the power button to activate the battery and check the level.

• The aircraft includes internal storage and supports microSD cards.

• Use the USB-C port for charging if needed.

• Unfold all arms.

• When the right rear arm is unfolded, the aircraft powers on automatically.

• Alternatively, press the power button once, then press and hold it for 2 seconds to power on manually.

2. Set Up the Remote Controller

• Unfold the antennas downward.

• Extend the screen arm to power on the controller.

• Follow the on-screen prompts to: Connect to Wi-Fi, set time zone, date, and time, and log in with your DJI Account (register if new).

• After activation, tap Start to go through the function guide.

• If the status LED blinks cyan, the control stick is off-centre.

• Launch DJI Fly and follow the calibration prompts.

3. Activate the Aircraft

• Launch the DJI Fly app.

• Follow on-screen steps to activate the drone (internet required).

• After activation, the aircraft is automatically bound to the remote controller.

4. DJI Care Refresh (Optional)

• If you purchased or plan to purchase DJI Care Refresh, complete the process within 48 hours of activation.

• You can skip this step if not needed.

5. Firmware Update

• If prompted, tap to enter the firmware update screen.

• Tap Update to install the latest firmware for all devices.

• Do not power off the aircraft or exit the DJI Fly app during the update.

• After updating, the aircraft will automatically power off.

6. Pre-Flight Setup

• Fly in an open, unobstructed area.

• Make sure the propellers and battery are securely installed.

• Place the drone on level ground with the rear facing you.

• Set the flight mode switch to Normal.

• Open System Settings > Safety in DJI Fly: Set Obstacle Avoidance Action to Bypass or Brake. Set RTH Height above the tallest nearby object

• Confirm that the GNSS icon is white before takeoff.

7. Takeoff and Landing

Auto Takeoff

• Tap the Takeoff icon on the left and hold the prompt to lift off.

• The drone will hover at a safe altitude.

Auto Landing

• Tap the Landing icon and hold the prompt to land and stop the motors.

Manual Takeoff

• Push both control sticks inward or outward to start the motors.

• Once spinning, release the sticks and gently push the left stick up to take off.

Manual Landing

• Pull the left stick down to descend.

• After landing, keep holding the stick down until the motors stop.

8. Basic Flight Controls

• Left Stick Up/Down – Ascend / Descend

• Left Stick Left/Right – Yaw (rotate aircraft)

• Right Stick Up/Down – Fly forward / backward

• Right Stick Left/Right – Fly sideways (left/right)

• Always keep the aircraft within optimal signal range.

9. Camera Operation

• Focus/Shutter Button: Half-press to autofocus. Full-press to take a photo

• Record Button: Press once to start or stop recording

• Left Dial: Adjust gimbal tilt

• Right Dial: Zoom in/out

• Tap the Camera icon (bottom right in DJI Fly) to switch between auto and manual modes.

• Use the Parameter Menu for advanced settings.

• Tap to switch cameras: 2.5X – Medium tele. 6X – Telephoto. 1X – Wide angle.

• Rotate the screen to toggle between landscape and portrait shooting.

• Tap the Playback icon to view or download footage.

10. Return to Home (RTH)

• Press and hold the RTH button on the controller, or

• Tap the RTH icon in the app and hold the confirmation.

• The drone will return to its last recorded home point and land.

11. Power Off and Pack Down

• Press, then press and hold the aircraft's power button for 2 seconds to turn it off.

• Fold the arms and propellers.

• Install the gimbal protector, snap the cover into the buckle, and tighten the strap.

Remote Controller

• Fold the screen arms – control sticks auto-store.

• Press, then press and hold the power button for 2 seconds to turn off.

• Fold the antennas.

Drone cover

If you haven't already purchased drone insurance, we recommend heliguy™ Repair Refresh.

It covers accidental damage and maintenance for 12 months, includes free UK shipping, one-off repair or replacement, and UK-based support.

It’s up to 45% cheaper than DJI Care Refresh, with cover ending after your first successful claim. Purchase within 7 days of receiving your drone and choose the option that matches your Mavic 4 Pro package.

Mavic 4 Pro Repair Refresh options:

1. Mavic 4 Pro

2. Mavic 4 Pro Fly More Combo (RC 2)

3. Mavic 4 Pro Creator Combo

Summary

This guide has walked you through the essential steps to set up, activate, and operate your DJI Mavic 4 Pro and RC Pro 2.

From powering on the drone and controller to performing safe takeoff, flight, and landing, you now have the knowledge to begin flying confidently.

Always follow safety checks and keep your firmware up to date for the best experience.
