Comparing The DJI Matrice 200 Series
Find out what each model (Matrice 200, Matrice 210 & Matrice 210 RTK) offers and how these exceptional commercial quadcopters benefit enterprise applications. ... Read More
UPDATE 05/04/2017: We have received some additional information regarding geotagging and base station usage for the Matrice 200 series from DJI - see their comments below: " X4S and X5S are geotagged with RTK, but the coordinates are dependent on the position of the GPS antenna, not the camera. The related position of camera and antenna is not estimated yet. The reference station cannot be centred on given control points, so it can not directly be used for surveying. However, POS data can be export via SDK." "It also supports connecting to Trimble Base station by using 4G, it can reach ranges of up to 30km." - Bart Vandervoort, DJI Netherlands
DJI’s Matrice 200 series has proved instantly popular with those looking to undertake commercial work with SUAs. With three available models offering various levels of modular functionality and positioning support, there’s a decent amount of choice for those interested in these stellar rigs. Before you settle on which M200 is right for you, it’s worth taking a look through our comparison so that you’re clued up on all the necessary specifications, features and varied levels of performance so that you make the right decision for both yourself and your business.
The DJI Matrice 200 Series – Overview & Specs
The M200, M210 and M210 RTK have all been designed with industrial end-users in mind, these are enterprise products and aren’t intended for the consumer market. This is clear, not only in their appearance but in their modular construction allowing (in the case of the M210 and M210 RTK) the attachment of multiple sensors to create an unparalleled aerial surveying tool. Every model is also fitted with an ADS-B receiver (trademarked as DJI AirSense) which improves safety by keeping you informed of any manned aircraft in the area, urgent airspace notices and temporary restrictions that may be in place. This guide has been designed to provide you with an overview of each of the models and what you can expect in terms of functionality and performance. Here are the specifications for the Matrice 200, 210 and 210 RTK to show how they line up against one another.
1488196099Matrice_200-small.png Matrice 200 | 1488196180Matrice_210-small.png Matrice 210 | 1488196209Matrice_210_RTK-small.png Matrice 210 RTK |
#### Package Dimensions | 790×390×290mm | 790×390×290mm | 790×390×290mm |
#### Dimensions (unfolded) | 887mm x 880mm x 378mm | 887mm x 880mm x 378mm | 887mm x 880mm x 408mm |
#### Dimensions (folded) | 716mm x 220mm x 236mm | 716mm x 220mm x 236mm | 716mm x 242mm x 236mm |
#### Folding Method | Folded Inward | Folded Inward | Folded Inward |
#### Diagonal Wheelbase | 643 mm | 643 mm | 643 mm |
#### Number of Batteries | 2 | 2 | 2 |
#### Weight | 3.80KG (TB50) 4.53KG (TB55) | 3.84KG (TB50) 4.57KG (TB55) | 4.27KG (TB50) 5.0KG (TB55) |
#### Max Takeoff Weight | 6.14KG | 6.14KG | 6.14KG |
#### Max Payload | 2.34KG (2 TB50) 1.61KG (2 TB55) | 2.3KG (2 TB50) 1.57KG (2 TB55) | 1.87KG (2 TB50) 1.14KG (2 TB55) |
#### Hovering Accuracy | P-mode with GPS: Vertical: ±0.5m or ±0.1m, Downward Vision System enabled; Horizontal: ±1.5m or ±0.3m, Downward Vision System enabled | During safe flights: Vertical: ±0.5,Downward Vision System enabled: ±0.1; Horizontal: ±1.5, Downward Vision System enabled: ±0.3 | P-mode with GPS: Vertical: ±±0.5 m or ±0.1 m, Downward Vision System enabled; Horizontal: ±1.5 m ±0.3 m, Downward Vision System enabled |
#### Max Angular Velocity | Pitch: 300°/s;Yaw: 150°/s | Pitch: 300°/s;Yaw: 150°/s | Pitch: 300°/s;Yaw: 150°/s |
#### Max Pitch Angle | P Mode: 35° (Forward Vision System enabled: 25°); A Mode: 35°;S Mode: 35° | P Mode: 35° (Forward Vision System enabled: 25°); A Mode: 35°;S Mode: 35° | P Mode: 35° (Forward Vision System enabled: 25°); A Mode: 35°;S Mode: 35° |
#### Max Ascent Speed | 5 m/s | 5 m/s | 5 m/s |
#### Max Descent Speed | 3 m/s | 3 m/s | 3 m/s |
#### Max Speed | S-Mode 23m/s; P-Mode 17m/s; A-Mode 23m/s | S-Mode 23m/s; P-Mode 17m/s; A-Mode 23m/s | P-mode: 17 m/s; S-mode/A-mode: 23 m/s |
#### Max Service Ceiling Above Sea Level | 2500m | 2500m | 2500m |
#### Max Wind Resistance | 10 m/s | 10 m/s | 10 m/s |
#### Max Flight Time | 27min (No Payload, with TB50) 38min (No Payload, with TB55) 13min (6kg Payload, with TB50) 24min (6kg Payload, with TB55) | 27min (No Payload, with TB50) 38min (No Payload, with TB55) 12min (6kg Payload, with TB50) 24min (6kg Payload, with TB55) | 23min (No Payload, with TB50) 32min (No Payload, with TB55) 13min (6kg Payload, with TB50) 24min (6kg Payload, with TB55) |
#### Motor Model | DJI 3515 | DJI 3515 | DJI 3515 |
#### Propeller Model | 1760S | 1760S | 1760S |
#### Operating Temperature | -20° to 45° C | -20° to 45° C | -20° to 45° C |
#### IP Rating | IP43 | IP43 | IP43 |
Gimbal Installation
#### Downward Gimbal Mount | Supported | Supported | Supported |
#### Upward Gimbal Mount | Not Supported | Supported | Supported |
#### Downward Dual Gimbal | Not Supported | Supported | Supported |
Gimbals
#### Compatible Gimbals | Zenmuse X4S; Zenmuse X5S; Zenmuse Z30; Zenmuse XT | Zenmuse X4S; Zenmuse X5S; Zenmuse Z30; Zenmuse XT | Zenmuse X4S; Zenmuse X5S; Zenmuse Z30; Zenmuse XT |
Battery (Standard)
#### Model | TB50 | TB50 | TB50 |
#### Capacity | 4280 mAh | 4280 mAh | 4280 mAh |
#### Voltage | 22.8V | 22.8V | 22.8V |
#### Battery Type | LiPo 6S | LiPo 6S | LiPo 6S |
#### Energy | 97.58 Wh | 97.58 Wh | 97.58 Wh |
#### Net Weight | Approx. 520 g | Approx. 520 g | Approx. 520 g |
#### Operating Temperature | -20°C to 40°C | -20°C to 40°C | -20°C to 40°C |
#### Storage Temperature | Storage Temperature Less than 3 months: -20° to 45°C; More than 3 months: 22° to 28°C | Storage Temperature Less than 3 months: -20° to 45°C; More than 3 months: 22° to 28°C | Storage Temperature Less than 3 months: -20° to 45°C; More than 3 months: 22° to 28°C |
#### Charging Temperature | 5° to 40°C | 5° to 40°C | 5° to 40°C |
#### Max Charging Power | 180 W | 180 W | 180 W |
Battery (Optional)
#### Model | TB55 | TB55 | TB55 |
#### Capacity | 7660 mAh | 7660 mAh | 7660 mAh |
#### Voltage | 22.8V | 22.8V | 22.8V |
#### Battery Type | LiPo 6S | LiPo 6S | LiPo 6S |
#### Energy | 176.93 Wh | 176.93 Wh | 176.93 Wh |
#### Net Weight | Approx. 885 g | Approx. 885 g | Approx. 885 g |
#### Operating Temperature | -20°C to 45°C | -20°C to 45°C | -20°C to 45°C |
#### Storage Temperature | Storage Temperature Less than 3 months: -20° to 45°C; More than 3 months: 22° to 28°C | Storage Temperature Less than 3 months: -20° to 45°C; More than 3 months: 22° to 28°C | Storage Temperature Less than 3 months: -20° to 45°C; More than 3 months: 22° to 28°C |
#### Charging Temperature | 5° to 40°C | 5° to 40°C | 5° to 40°C |
#### Max Charging Power | 180 W | 180 W | 180 W |
Remote Controller
#### Model | GL6D10A | GL6D10A | GL6D10A |
#### Operating Frequency | 2.400-2.483 GHz; 5.725-5.850 GHz | 2.400-2.483 GHz; 5.725-5.850 GHz | 2.400-2.483 GHz; 5.725-5.850 GHz |
#### Max Transmitting Distance (unobstructed, free of interference) | 2.4 GHz: 7 km (FCC); 3.5 km (CE); 4 km (SRRC) 5.8 GHz: 7 km (FCC); 2 km (CE); 5 km (SRRC) | 2.4 GHz: 7 km (FCC); 3.5 km (CE); 4 km (SRRC) 5.8 GHz: 7 km (FCC); 2 km (CE); 5 km (SRRC) | 2.4 GHz: 7 km (FCC); 3.5 km (CE); 4 km (SRRC) 5.8 GHz: 7 km (FCC); 2 km (CE); 5 km (SRRC) |
#### EIRP | 2.4 GHz: 26 dBm (FCC); 17 dBm (CE); 20 dBm (SRRC) 5.8 GHz: 28 dBm (FCC); 14 dBm (CE); 20 dBm (SRRC) | 2.4 GHz: 26 dBm (FCC); 17 dBm (CE); 20 dBm (SRRC) 5.8 GHz: 28 dBm (FCC); 14 dBm (CE); 20 dBm (SRRC) | 2.4 GHz: 26 dBm (FCC); 17 dBm (CE); 20 dBm (SRRC) 5.8 GHz: 28 dBm (FCC); 14 dBm (CE); 20 dBm (SRRC) |
#### Video Output Ports | USB, HDMI | USB, HDMI | USB, HDMI |
#### Power Supply | Built-in battery | Built-in battery | Built-in battery |
#### Charging | DJI charger | DJI charger | DJI charger |
#### Dual User Capability | Host-and-Slave connection | Host-and-Slave connection | Host-and-Slave connection |
#### Mobile Device Holder | Tablet or Smart Phone | Tablet or Smart Phone | Tablet or Smart Phone |
#### Max Mobile Device Width | 170 mm | 170 mm | 170 mm |
#### Output Power | 9 W (Without supplying power to smart device) | 9 W (Without supplying power to smart device) | 9 W (Without supplying power to smart device) |
#### Operating Temperature | -20°C to 40°C | -20°C to 40°C | -20°C to 40°C |
#### Storage Temperature | Storage Temperature Less than 3 months: -20° to 45°C; More than 3 months: 22° to 28°C | Storage Temperature Less than 3 months: -20° to 45°C; More than 3 months: 22° to 28°C | Storage Temperature Less than 3 months: -20° to 45°C; More than 3 months: 22° to 28°C |
#### Charging Temperature | 0° to 40°C | 0° to 40°C | 0° to 40°C |
#### Battery | 6000mAh 2S LiPo | 6000mAh 2S LiPo | 6000mAh 2S LiPo |
#### USB Supply Power | iOS: 1 A @ 5.2 V (Max); Android: 1.5 A @ 5.2 V (Max) | iOS: 1 A @ 5.2 V (Max); Android: 1.5 A @ 5.2 V (Max) | iOS: 1 A @ 5.2 V (Max); Android: 1.5 A @ 5.2 V (Max) |
Charger
#### Model | IN2C180 | IN2C180 | IN2C180 |
#### Voltage | 26.1 V | 26.1 V | 26.1 V |
#### Rated Power | 180 W | 180 W | 180 W |
DJI GO APP
#### Name | DJI GO 4 | DJI GO 4 | DJI GO 4 |
#### Mobile Device System Requirements | iOS 9.0 or later, Android 4.4.0 or later | iOS 9.0 or later, Android 4.4.0 or later | iOS 9.0 or later, Android 4.4.0 or later |
#### Supported Mobile Devices | iOS: iPhone 5s, iPhone SE, iPhone 6, iPhone 6 Plus, iPhone 6s, iPhone 6s Plus, iPhone 7, iPhone 7 Plus, iPad Air, iPad Air Wi-Fi + Cellular, iPad mini 2, iPad mini 2 Wi-Fi + Cellular, iPad Air 2, iPad Air 2 Wi-Fi + Cellular, iPad mini 3, iPad mini 3 Wi-Fi + Cellular, iPad mini 4 and iPad mini 4 Wi-Fi + Cellular. This app is optimised for iPhone 7, iPhone 7 Plus. Android:Samsung tabs 705c, Samsung S6, Samsung S5, Samsung NOTE4, Samsung NOTE3, Google Nexus 6p, Nexus 9, Google Nexus 7 II, Ascend Mate7, Huawei P8 Max, Huawei Mate 8, LG V20, Nubia Z7 mini, Sony Xperia Z3, MI 3, MI PAD, Smartisan T1. *Support for additional devices available as testing and development continues. | iOS: iPhone 5s, iPhone SE, iPhone 6, iPhone 6 Plus, iPhone 6s, iPhone 6s Plus, iPhone 7, iPhone 7 Plus, iPad Air, iPad Air Wi-Fi + Cellular, iPad mini 2, iPad mini 2 Wi-Fi + Cellular, iPad Air 2, iPad Air 2 Wi-Fi + Cellular, iPad mini 3, iPad mini 3 Wi-Fi + Cellular, iPad mini 4 and iPad mini 4 Wi-Fi + Cellular. This app is optimised for iPhone 7, iPhone 7 Plus. Android:Samsung tabs 705c, Samsung S6, Samsung S5, Samsung NOTE4, Samsung NOTE3, Google Nexus 6p, Nexus 9, Google Nexus 7 II, Ascend Mate7, Huawei P8 Max, Huawei Mate 8, LG V20, Nubia Z7 mini, Sony Xperia Z3, MI 3, MI PAD, Smartisan T1. *Support for additional devices available as testing and development continues. | iOS: iPhone 5s, iPhone SE, iPhone 6, iPhone 6 Plus, iPhone 6s, iPhone 6s Plus, iPhone 7, iPhone 7 Plus, iPad Air, iPad Air Wi-Fi + Cellular, iPad mini 2, iPad mini 2 Wi-Fi + Cellular, iPad Air 2, iPad Air 2 Wi-Fi + Cellular, iPad mini 3, iPad mini 3 Wi-Fi + Cellular, iPad mini 4 and iPad mini 4 Wi-Fi + Cellular. This app is optimised for iPhone 7, iPhone 7 Plus. Android:Samsung tabs 705c, Samsung S6, Samsung S5, Samsung NOTE4, Samsung NOTE3, Google Nexus 6p, Nexus 9, Google Nexus 7 II, Ascend Mate7, Huawei P8 Max, Huawei Mate 8, LG V20, Nubia Z7 mini, Sony Xperia Z3, MI 3, MI PAD, Smartisan T1. *Support for additional devices available as testing and development continues. |
Forward Vision System
#### Obstacle Sensing Range | 0.7-30 m | 0.7-30 m | 0.7-30 m |
#### FOV | Horizontal 60°,Vertical 54° | Horizontal 60°,Vertical 54° | Horizontal 60°,Vertical 54° |
#### Operating Environment | Surfaces with clear patterns and adequate lighting (> 15 lux) | Surfaces with clear patterns and adequate lighting (> 15 lux) | Surfaces with clear patterns and adequate lighting (> 15 lux) |
Upward Infrared Sensor
#### Obstacle Sensing Range | 0-5 m | 0-5 m | 0-5 m |
#### FOV | ±5° | ±5° | ±5° |
#### Operating Environment | Large-sized object with diffuse reflecting surface or high reflective rate (>10%) | Large, diffuse and reflective obstacles (reflectivity >10%) | Large-sized object with diffuse reflecting surface or high reflective rate (>10%) |
Downward Vision System
#### Velocity Range | < 10 m/s at the height of 2 m | < 10 m/s at the height of 2 m | < 10 m/s at the height of 2 m |
#### Altitude Range | < 10m | < 10m | < 10m |
#### Operating Range | < 10m | < 10m | < 10m |
#### Operating Environment | Surfaces with clear patterns and adequate lighting (> 15 lux) | Surfaces with clear patterns and adequate lighting (> 15 lux) | Surfaces with clear patterns and adequate lighting (> 15 lux) |
#### Ultrasonic Sensor Operating Range | 10-500 cm | 10-500 cm | 10-500 cm |
#### Ultrasonic Sensor Operating Environment | Non-absorbing material, rigid surface (thick indoor carpeting will reduce performance) | Non-absorbing material, rigid surface (thick indoor carpeting will reduce performance) | Non-absorbing material, rigid surface (thick indoor carpeting will reduce performance) |
Now we will look at each model individually. If you have any questions after looking through this guide, our team are available on 0191 296 1024 or info@heliguy.com to help you decide.
DJI Matrice 200
Heliguy-Diagram-Matrice_200.png The Matrice 200 is the basic version of this industrial quadcopter which, while lacking some of the additional features of the more advanced versions (i.e. dual and upward gimbal mounting and RTK functionality) is still a sturdy solution which can benefit a range of industrial uses due to its compatibility with the following Zenmuse cameras:
DJI Zenmuse Z30: 30x aerial zoom camera designed for inspection work.
DJI Zenmuse XT: A team effort from FLIR and DJI enabling highly accurate thermal and radiographic aerial surveys.
DJI Zenmuse X4S: Great quality imagery engineered by DJI.
DJI Zenmuse X5S: The pinnacle of Zenmuse camera quality, originally designed for the filmmaking with the Inspire 2.
Please Note: The above cameras are compatible with all airframes in this series. This versatility coupled with an IP43 weatherproofed rating makes the M200 a powerful aerial imaging rig perfect for surveying tasks in challenging scenarios. Add in the dual battery system for added redundancy and on-site safety (as well as compatibility with the new TB55s allowing for extended flight times) and you’re looking at a robust commercial solution.
___________________
M200 - Key Features
FPV Camera
Dual-battery System
FlightAutonomy
IP43 Weatherproofing
ADS-B Receiver
___________________
DJI Matrice 210
Heliguy-Diagram-Matrice_210.png The M210 configuration features everything that you can expect from the standard Matrice 200 with the addition of universal ports and the option for multiple payload configurations. The Matrice 210 enables you to mount dual gimbals underneath the aircraft (e.g. the Zenmuse XT and Zenmuse Z30 for simultaneous zoom imagery and thermal data capture) and you also have the option to top mount a gimbal for a different viewpoint (especially useful for bridge inspections which require an upwards vertical perspective). Please Note: You can’t use an upward and downward camera simultaneously. This mid-range model will appeal to the majority of businesses looking to implement one of the Matrice 200 series aircraft into their service offering. It comes with more functionality than the base M200 as standard and, for those not overly concerned about the positioning accuracy of RTK, the Matrice 210 is the ideal industrial airframe.
___________________
M210 - Key Features
FPV Camera
Dual-battery System
FlightAutonomy
IP43 Weatherproofing
ADS-B Receiver
Multiple Payload Configurations (Dual and Top Mounted)
Universal Ports
___________________
DJI Matrice 210 RTK
Heliguy-Diagram-Matrice_210_RTK.png The top of the line model in the M200 range is the Matrice 210 RTK. This aircraft is kitted out with everything featured in the both the M200 and M210 including the ability to choose how you mount your gimbals. What sets it apart, however, is the built-in RTK functionality from DJI which, according to the manufacturer, ensures millimetre-precision navigation. If you’re looking for the absolute best of the bunch, it’s hard to find a more capable industrial rig than the Matrice 210 RTK. Although the price disparity (call 0191 296 1024 for details on costs) between the Matrice 210 and 210 RTK might prompt some businesses to opt for the mid-range model, if you’re willing to invest in this premium aircraft, you will have access to one of the most powerful, adaptable commercial SUA solutions available.
___________________
M210 RTK - Key Features
FPV Camera
Dual-battery System
FlightAutonomy
IP43 Weatherproofing
ADS-B Receiver
Multiple Payload Configurations (Dual and Top Mounted)
Universal Ports
Built-in RTK
___________________
Matrice 200 Series - Additional Information
Now that you know what each aircraft in the Matrice 200 series has to offer, let's take a look at some of the peripherals and software that have been developed to work seamlessly with these commercial quadcopters.
A New Generation of Flight Management
Alongside the Matrice 200 range, DJI also announced their new FlightHub software. While information is currently limited, we can confirm that it is a web-based software package which allows teams to share real-time data with offsite colleagues over an internet connection. Promising an intuitive ‘control centre’, DJI FlightHub will let companies plan flights for entire fleets and keep track of each aircraft's status. Offsite personnel can monitor live feeds while remotely controlling drone’s camera and gimbal. flighthub.png This feature-rich software solution will also reportedly enable managers to plan flights in advance using waypoints and dynamic geofencing. The applications for this include situation control centres remotely keeping track of teams on the ground or company engineers inspecting infrastructure networks without having to leave the office. It’s also worth noting that the M200 series is compatible with DJI's Mobile and Onboard Software Development Kit (SDK), which gives programmers the ability to design customised solutions for flight plans, data collation and analysis.
Compatible Accessories
The Matrice 200 is compatible with a range of accessories, here are some of the most interesting currently being touted by DJI: DJI Goggles: The M200 series pairs with the upcoming 'DJI Goggles', which display an 85-degree view from the drone in full 1080p. Dual Controllers: The master and slave controller range has been extended to 328ft and users have the option to switch between 2.4GHz and 5.8GHz frequencies to ensure greater signal stability. A Choice of Batteries: The M200 series offers two battery versions – a standard 95Wh version (TB50) and a more powerful version of 174Wh (TB55) with a flight time of up to 38 minutes.
Matrice 200 Series - Frequently Asked Questions
Aircraft
What cameras and gimbals are the M200 series compatible with?
The M200 series currently supports the Zenmuse X4S, Zenmuse X5S, Zenmuse XT and Zenmuse Z30 cameras.
// <![CDATA[ vs.q(function(){$('.cms-page--template-sections__accordion-text-800594 .cms-page__accordion-content').hide();$('.cms-page--template-sections__accordion-text-800594 .product-tabs').click(function(){$('.cms-page--template-sections__accordion-text-800594 .cms-page__accordion-content').slideToggle();$(".cms-page--template-sections__accordion-text-800594 .product-tabs__list__item").toggleClass('active');$(".cms-page--template-sections__accordion-text-800594 .product-tabs-image_wrapper").toggleClass('active');});}); // ]]>
Does the M200 series have an Obstacle Avoidance/FlightAutonomy system?
Yes, the M200 series includes a robust FlightAutonomy system with a total of 7 sensors. Its Forward Vision System is capable of detecting obstacles up to 30 meters ahead, while the upward facing infrared sensors can sense obstacles within a 5-meter range. A downward facing vision positioning system enables precision hovering and landing.
// <![CDATA[ vs.q(function(){$('.cms-page--template-sections__accordion-text-655395 .cms-page__accordion-content').hide();$('.cms-page--template-sections__accordion-text-655395 .product-tabs').click(function(){$('.cms-page--template-sections__accordion-text-655395 .cms-page__accordion-content').slideToggle();$(".cms-page--template-sections__accordion-text-655395 .product-tabs__list__item").toggleClass('active');$(".cms-page--template-sections__accordion-text-655395 .product-tabs-image_wrapper").toggleClass('active');});}); // ]]>
What is the difference between the M100, M200 and M600?
The main difference between the M200 series and the rest of the Matrice line of drones is its closed-shell body, which brings added portability, ease-of-use and ruggedness. Additionally, the M210 models can easily accommodate multiple payload configurations, something not previously seen on any drone.
// <![CDATA[ vs.q(function(){$('.cms-page--template-sections__accordion-text-108872 .cms-page__accordion-content').hide();$('.cms-page--template-sections__accordion-text-108872 .product-tabs').click(function(){$('.cms-page--template-sections__accordion-text-108872 .cms-page__accordion-content').slideToggle();$(".cms-page--template-sections__accordion-text-108872 .product-tabs__list__item").toggleClass('active');$(".cms-page--template-sections__accordion-text-108872 .product-tabs-image_wrapper").toggleClass('active');});}); // ]]>
Is a case included with my M200 series drone?
Yes, your M200 series drone comes with a travel case customised to securely transport your model. The case comes with enough space to fit 6 TB50 or TB55 batteries, 2 gimbals, 2 sets of propellers, one controller, one charger and charger hub, a CrystalSky tablet or Apple iPad.
// <![CDATA[ vs.q(function(){$('.cms-page--template-sections__accordion-text-351902 .cms-page__accordion-content').hide();$('.cms-page--template-sections__accordion-text-351902 .product-tabs').click(function(){$('.cms-page--template-sections__accordion-text-351902 .cms-page__accordion-content').slideToggle();$(".cms-page--template-sections__accordion-text-351902 .product-tabs__list__item").toggleClass('active');$(".cms-page--template-sections__accordion-text-351902 .product-tabs-image_wrapper").toggleClass('active');});}); // ]]>
Does my M200 series drone need to be regularly checked when flying in sandy environments?
When flying in sandy and similar environments, pilots should regularly check their drone after flying to extend its lifetime as the closed-shell body is not completely protected against fine particles. Specifically, pilots should check the arm-closing mechanism, and motors for loose particles that could potentially harm the aircraft's internals.
// <![CDATA[ vs.q(function(){$('.cms-page--template-sections__accordion-text-741616 .cms-page__accordion-content').hide();$('.cms-page--template-sections__accordion-text-741616 .product-tabs').click(function(){$('.cms-page--template-sections__accordion-text-741616 .cms-page__accordion-content').slideToggle();$(".cms-page--template-sections__accordion-text-741616 .product-tabs__list__item").toggleClass('active');$(".cms-page--template-sections__accordion-text-741616 .product-tabs-image_wrapper").toggleClass('active');});}); // ]]>
Can I carry the M200 batteries on a commercial aeroplane?
Most airlines allow TB50 batteries to be carried onto the airplane. You are likely to encounter issues when carrying TB55 batteries as they exceed allotted size for many airlines. Before planning a project, we suggest checking with your airline in advance. When transporting batteries please discharge them to below 30% maximum capacity for maximum safety.
// <![CDATA[ vs.q(function(){$('.cms-page--template-sections__accordion-text-274073 .cms-page__accordion-content').hide();$('.cms-page--template-sections__accordion-text-274073 .product-tabs').click(function(){$('.cms-page--template-sections__accordion-text-274073 .cms-page__accordion-content').slideToggle();$(".cms-page--template-sections__accordion-text-274073 .product-tabs__list__item").toggleClass('active');$(".cms-page--template-sections__accordion-text-274073 .product-tabs-image_wrapper").toggleClass('active');});}); // ]]>
What happens if one battery fails?
The M200 series continuously checks battery status and will notify you through the DJI GO 4 app if a battery malfunctions. In this case, please land the aircraft immediately.
// <![CDATA[ vs.q(function(){$('.cms-page--template-sections__accordion-text-294571 .cms-page__accordion-content').hide();$('.cms-page--template-sections__accordion-text-294571 .product-tabs').click(function(){$('.cms-page--template-sections__accordion-text-294571 .cms-page__accordion-content').slideToggle();$(".cms-page--template-sections__accordion-text-294571 .product-tabs__list__item").toggleClass('active');$(".cms-page--template-sections__accordion-text-294571 .product-tabs-image_wrapper").toggleClass('active');});}); // ]]>
For the M210 RTK model, is there any extra setup required for this unit?
Since the RTK unit is built into the drone, you will simply have to fold out the arms to get the built-in unit fully operational and turn on the ground control unit.
// <![CDATA[ vs.q(function(){$('.cms-page--template-sections__accordion-text-720873 .cms-page__accordion-content').hide();$('.cms-page--template-sections__accordion-text-720873 .product-tabs').click(function(){$('.cms-page--template-sections__accordion-text-720873 .cms-page__accordion-content').slideToggle();$(".cms-page--template-sections__accordion-text-720873 .product-tabs__list__item").toggleClass('active');$(".cms-page--template-sections__accordion-text-720873 .product-tabs-image_wrapper").toggleClass('active');});}); // ]]>
Applications
I’m a filmmaker, is this the best option for me?
Although the M200 series’ water resistant build, long flight time and compatible cameras might be attractive to filmmakers, DJI recommends professional filmmakers use the Inspire 2 due to its available SSD slot, transforming design for an unobstructed view and CineCore image processing system.
// <![CDATA[ vs.q(function(){$('.cms-page--template-sections__accordion-text-230007 .cms-page__accordion-content').hide();$('.cms-page--template-sections__accordion-text-230007 .product-tabs').click(function(){$('.cms-page--template-sections__accordion-text-230007 .cms-page__accordion-content').slideToggle();$(".cms-page--template-sections__accordion-text-230007 .product-tabs__list__item").toggleClass('active');$(".cms-page--template-sections__accordion-text-230007 .product-tabs-image_wrapper").toggleClass('active');});}); // ]]>
I’m a power line/telecom tower inspector and worry about interference affecting the safety of my inspection, which M200 series model and payload will help me operate more safely?
For operators that expect to experience electrical or signal interference during flight we suggest using the M210 RTK model and/or the Zenmuse Z30 zoom camera for optimal safety. The built-in RTK unit on the M210 RTK model enables the drone to hover with centimeter-level accuracy due to the improved GPS data, making slight interferences to the transmission system less potentially
// <![CDATA[ vs.q(function(){$('.cms-page--template-sections__accordion-text-273991 .cms-page__accordion-content').hide();$('.cms-page--template-sections__accordion-text-273991 .product-tabs').click(function(){$('.cms-page--template-sections__accordion-text-273991 .cms-page__accordion-content').slideToggle();$(".cms-page--template-sections__accordion-text-273991 .product-tabs__list__item").toggleClass('active');$(".cms-page--template-sections__accordion-text-273991 .product-tabs-image_wrapper").toggleClass('active');});}); // ]]>
Payloads
What cameras are compatible with the M200 series?
The M200 series of drones are compatible with DJI’s Zenmuse X4S, X5S, XT and Z30 cameras. To learn more about payload options and configurations visit here.
// <![CDATA[ vs.q(function(){$('.cms-page--template-sections__accordion-text-572365 .cms-page__accordion-content').hide();$('.cms-page--template-sections__accordion-text-572365 .product-tabs').click(function(){$('.cms-page--template-sections__accordion-text-572365 .cms-page__accordion-content').slideToggle();$(".cms-page--template-sections__accordion-text-572365 .product-tabs__list__item").toggleClass('active');$(".cms-page--template-sections__accordion-text-572365 .product-tabs-image_wrapper").toggleClass('active');});}); // ]]>
What dual gimbal configurations are supported by the M210 models?
Please refer to the information below for an explanation of how to properly mount your dual gimbal configuration. Left and right is determined from the perspective of looking directly at the drone from the front. Left Gimbal Port: Zenmuse XT or Zenmuse Z30 Right Gimbal Port: Zenmuse X4S, X5S, Z30, XT
// <![CDATA[ vs.q(function(){$('.cms-page--template-sections__accordion-text-798998 .cms-page__accordion-content').hide();$('.cms-page--template-sections__accordion-text-798998 .product-tabs').click(function(){$('.cms-page--template-sections__accordion-text-798998 .cms-page__accordion-content').slideToggle();$(".cms-page--template-sections__accordion-text-798998 .product-tabs__list__item").toggleClass('active');$(".cms-page--template-sections__accordion-text-798998 .product-tabs-image_wrapper").toggleClass('active');});}); // ]]>
How do I mount an upward payload?
Screw the upward gimbal mount on top of the drone, and then twist to lock the camera into position. To ensure stable GNSS lock while using this configuration, please mount the included GNSS receiver onto the side of the drone. For a more detailed explanation, you can find the manual in the downloads section of this webpage.
// <![CDATA[ vs.q(function(){$('.cms-page--template-sections__accordion-text-294978 .cms-page__accordion-content').hide();$('.cms-page--template-sections__accordion-text-294978 .product-tabs').click(function(){$('.cms-page--template-sections__accordion-text-294978 .cms-page__accordion-content').slideToggle();$(".cms-page--template-sections__accordion-text-294978 .product-tabs__list__item").toggleClass('active');$(".cms-page--template-sections__accordion-text-294978 .product-tabs-image_wrapper").toggleClass('active');});}); // ]]>
Can you fly with both the XT and Z30 at the same time?
When using the M210 or M210 RTK models, you can mount both the Zenmuse XT and Z30 downwards.
// <![CDATA[ vs.q(function(){$('.cms-page--template-sections__accordion-text-447368 .cms-page__accordion-content').hide();$('.cms-page--template-sections__accordion-text-447368 .product-tabs').click(function(){$('.cms-page--template-sections__accordion-text-447368 .cms-page__accordion-content').slideToggle();$(".cms-page--template-sections__accordion-text-447368 .product-tabs__list__item").toggleClass('active');$(".cms-page--template-sections__accordion-text-447368 .product-tabs-image_wrapper").toggleClass('active');});}); // ]]>
Can you mount a camera upwards and downwards at the same time?
The M200 series does not support the use of an upwards-mounted camera and a downwards-mounted camera at the same time. Instead, pilots can mount a camera upwards and rely on the built-in FPV camera to fly comfortably.
// <![CDATA[ vs.q(function(){$('.cms-page--template-sections__accordion-text-477253 .cms-page__accordion-content').hide();$('.cms-page--template-sections__accordion-text-477253 .product-tabs').click(function(){$('.cms-page--template-sections__accordion-text-477253 .cms-page__accordion-content').slideToggle();$(".cms-page--template-sections__accordion-text-477253 .product-tabs__list__item").toggleClass('active');$(".cms-page--template-sections__accordion-text-477253 .product-tabs-image_wrapper").toggleClass('active');});}); // ]]>
General
What mobile software programs are compatible with the M200 series?
To better control the M200 series, pilots can use the DJI Pilot or DJI GO 4 app. The DJI Pilot app is a new Android app for enterprise users designed to unleash the full potential of DJI’s enterprise drones. The user interface is streamlined for a straightforward experience, so pilots can focus on the task at hand. More features are built in – such as the ability to control the dual gimbal setup on the M210 models and flight planning – to uniquely support the DJI Enterprise product lines.
// <![CDATA[ vs.q(function(){$('.cms-page--template-sections__accordion-text-445640 .cms-page__accordion-content').hide();$('.cms-page--template-sections__accordion-text-445640 .product-tabs').click(function(){$('.cms-page--template-sections__accordion-text-445640 .cms-page__accordion-content').slideToggle();$(".cms-page--template-sections__accordion-text-445640 .product-tabs__list__item").toggleClass('active');$(".cms-page--template-sections__accordion-text-445640 .product-tabs-image_wrapper").toggleClass('active');});}); // ]]>
What’s new in the DJI Pilot app?
The DJI Pilot app builds on top of the controls in the DJI GO 4 app with the ability to swap between the feeds from 3 payloads (2 from dual gimbal setup and the FPV camera) and the ability to plan and automate complex flights with the same technology found in the DJI GS Pro app.
// <![CDATA[ vs.q(function(){$('.cms-page--template-sections__accordion-text-441309 .cms-page__accordion-content').hide();$('.cms-page--template-sections__accordion-text-441309 .product-tabs').click(function(){$('.cms-page--template-sections__accordion-text-441309 .cms-page__accordion-content').slideToggle();$(".cms-page--template-sections__accordion-text-441309 .product-tabs__list__item").toggleClass('active');$(".cms-page--template-sections__accordion-text-441309 .product-tabs-image_wrapper").toggleClass('active');});}); // ]]>
What programs can I use for creating reproducible flight plans for automated flight?
The M200 series is compatible with the DJI GS Pro iPad app for advanced flight planning. Android users can find the same technology built into the DJI Pilot app.
// <![CDATA[ vs.q(function(){$('.cms-page--template-sections__accordion-text-592621 .cms-page__accordion-content').hide();$('.cms-page--template-sections__accordion-text-592621 .product-tabs').click(function(){$('.cms-page--template-sections__accordion-text-592621 .cms-page__accordion-content').slideToggle();$(".cms-page--template-sections__accordion-text-592621 .product-tabs__list__item").toggleClass('active');$(".cms-page--template-sections__accordion-text-592621 .product-tabs-image_wrapper").toggleClass('active');});}); // ]]>
How long does it take to charge a remote controller? How long does it last on a full charge?
The remote controller is equipped with a 6,000mAh LiPo 2S battery. Fully charging the M200 series remote controller takes approximately 3 hours. It can be used for approximately 4 hours after being fully charged. When connecting the standard Battery Charger to the Battery Charging Hub, it takes about 90 minutes to charge 2 batteries and 180 minutes to charge 4 batteries.
// <![CDATA[ vs.q(function(){$('.cms-page--template-sections__accordion-text-809397 .cms-page__accordion-content').hide();$('.cms-page--template-sections__accordion-text-809397 .product-tabs').click(function(){$('.cms-page--template-sections__accordion-text-809397 .cms-page__accordion-content').slideToggle();$(".cms-page--template-sections__accordion-text-809397 .product-tabs__list__item").toggleClass('active');$(".cms-page--template-sections__accordion-text-809397 .product-tabs-image_wrapper").toggleClass('active');});}); // ]]>
Does my M200 series drone come with a Micro SD card?
Yes. Included in the box is a 16GB Micro SD card. It supports Micro SD cards up to 128GB.
// <![CDATA[ vs.q(function(){$('.cms-page--template-sections__accordion-text-461897 .cms-page__accordion-content').hide();$('.cms-page--template-sections__accordion-text-461897 .product-tabs').click(function(){$('.cms-page--template-sections__accordion-text-461897 .cms-page__accordion-content').slideToggle();$(".cms-page--template-sections__accordion-text-461897 .product-tabs__list__item").toggleClass('active');$(".cms-page--template-sections__accordion-text-461897 .product-tabs-image_wrapper").toggleClass('active');});}); // ]]>
What is the latency of the transmission system?
Below 220ms.
// <![CDATA[ vs.q(function(){$('.cms-page--template-sections__accordion-text-945040 .cms-page__accordion-content').hide();$('.cms-page--template-sections__accordion-text-945040 .product-tabs').click(function(){$('.cms-page--template-sections__accordion-text-945040 .cms-page__accordion-content').slideToggle();$(".cms-page--template-sections__accordion-text-945040 .product-tabs__list__item").toggleClass('active');$(".cms-page--template-sections__accordion-text-945040 .product-tabs-image_wrapper").toggleClass('active');});}); // ]]>
Can you use batteries charged at different levels?
The M200 series can take off if the power discrepancy of the two batteries is within 13%. If it is unable to take off, the DJI GO 4 app will inform you that “the power discrepancy in the two batteries is too large”.
// <![CDATA[ vs.q(function(){$('.cms-page--template-sections__accordion-text-867411 .cms-page__accordion-content').hide();$('.cms-page--template-sections__accordion-text-867411 .product-tabs').click(function(){$('.cms-page--template-sections__accordion-text-867411 .cms-page__accordion-content').slideToggle();$(".cms-page--template-sections__accordion-text-867411 .product-tabs__list__item").toggleClass('active');$(".cms-page--template-sections__accordion-text-867411 .product-tabs-image_wrapper").toggleClass('active');});}); // ]]>
Do I need to pair the batteries?
No, the batteries do not need to be paired with a particular M200 series drone before flying.
// <![CDATA[ vs.q(function(){$('.cms-page--template-sections__accordion-text-204287 .cms-page__accordion-content').hide();$('.cms-page--template-sections__accordion-text-204287 .product-tabs').click(function(){$('.cms-page--template-sections__accordion-text-204287 .cms-page__accordion-content').slideToggle();$(".cms-page--template-sections__accordion-text-204287 .product-tabs__list__item").toggleClass('active');$(".cms-page--template-sections__accordion-text-204287 .product-tabs-image_wrapper").toggleClass('active');});}); // ]]>
Does the M200 Series support the Adobe CinemaDNG and Apple ProRes?
No, the M200 series does not support these formats.
// <![CDATA[ vs.q(function(){$('.cms-page--template-sections__accordion-text-242054 .cms-page__accordion-content').hide();$('.cms-page--template-sections__accordion-text-242054 .product-tabs').click(function(){$('.cms-page--template-sections__accordion-text-242054 .cms-page__accordion-content').slideToggle();$(".cms-page--template-sections__accordion-text-242054 .product-tabs__list__item").toggleClass('active');$(".cms-page--template-sections__accordion-text-242054 .product-tabs-image_wrapper").toggleClass('active');});}); // ]]>
written by
James Willoughby
James joined heliguy™ in 2018 following a 13-year stint in print and online journalism, having worked on regional and weekly newspaper titles. He is responsible for spearheading heliguy™'s content strategy and social media delivery. James collaborates with DJI Enterprise's European marketing team to coordinate and produce case studies and helps organise events and webinars.
